Capacitive Touch RGB IPS TFT Display 4.3 LCD Screen 800x480
Capacitive Touch RGB IPS TFT Display 4.3 LCD Screen 800x480
Capacitive Touch RGB IPS TFT Display 4.3 LCD Screen 800x480
Capacitive Touch RGB IPS TFT Display 4.3 LCD Screen 800x480
Capacitive Touch RGB IPS TFT Display 4.3 LCD Screen 800x480
Capacitive Touch RGB IPS TFT Display 4.3 LCD Screen 800x480
Capacitive Touch RGB IPS TFT Display 4.3 LCD Screen 800x480
Capacitive Touch RGB IPS TFT Display 4.3 LCD Screen 800x480
Capacitive Touch RGB IPS TFT Display 4.3 LCD Screen 800x480
Capacitive Touch RGB IPS TFT Display 4.3 LCD Screen 800x480
Capacitive Touch RGB IPS TFT Display 4.3 LCD Screen 800x480
Capacitive Touch RGB IPS TFT Display 4.3 LCD Screen 800x480
Capacitive Touch RGB IPS TFT Display 4.3 LCD Screen 800x480
Capacitive Touch RGB IPS TFT Display 4.3 LCD Screen 800x480
Specifications
Touch Screen :
With capacitive touch
Packaging Details :
Tray + Inner Box + Carton
MOQ :
1 piece
Product Name :
4.3" 800x480 RGB LCD Capacitive Touch TFT And IPS Display 4.3 LCD Screen
Dimensions :
105.5mm x 67.2mm x 4.3mm
Color :
Color
Payment Terms :
T/T,L/C,Credit card,Cash
Supply Ability :
5000000000 pieces/year
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Display Size :
4.3 inch
Display Type :
4.3 Inch TFT Display
Operating Temperature :
-10°C to 60°C
Model Number :
KWH043ST42-C01
Place of Origin :
China
Interface :
40-Pin, 24 BIT RGB
Display Mode :
IPS LCD
Resolution :
800x480
Brand Name :
Formike
Viewing Angle :
All
Description

4.3" 800x480 RGB LCD Capacitive Touch TFT And IPS Display 4.3 LCD Screen

Capacitive Touch RGB IPS TFT Display 4.3

Product Name 4.3" 800x480 RGB LCD Capacitive Touch TFT And IPS Display 4.3 LCD Screen
LCD Size 4.3 Inch IPS TFT LCD Display Module
Display Mode Transmissive
Resolution 800x480
Outline Dimension (mm) 105.50x67.20x4.30
Active Area (mm) 95.04x53.86
Dot pitch (mm) 0.1188x0.1122
Viewing Direction ALL
Interface 24 BIT RGB Interface, 40 Pin
Color Depth 16M
Brightness (Cd/m2) 350
Contrast Ratio 800:1
Backlight 12 White LED

Backlight Supply

(Current/Voltage)

 60mA 12.8V
Touch Screen With Capacitive Touch Panel

* KWH043ST42-C01 is a Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight, CTP.

* It is 800x480 resolution IPS TFT LCD module.

* Backlight with different brightness options from 250 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.

Capacitive Touch RGB IPS TFT Display 4.3Capacitive Touch RGB IPS TFT Display 4.3
