RoHS 800x480 4.3 Inch IPS TFT LCD Display 40 Pin With Touch Screen 24 BIT RGB Interface
RoHS 800x480 4.3 Inch IPS TFT LCD Display 40 Pin With Touch Screen 24 BIT RGB Interface
RoHS 800x480 4.3 Inch IPS TFT LCD Display 40 Pin With Touch Screen 24 BIT RGB Interface
RoHS 800x480 4.3 Inch IPS TFT LCD Display 40 Pin With Touch Screen 24 BIT RGB Interface
RoHS 800x480 4.3 Inch IPS TFT LCD Display 40 Pin With Touch Screen 24 BIT RGB Interface
RoHS 800x480 4.3 Inch IPS TFT LCD Display 40 Pin With Touch Screen 24 BIT RGB Interface
RoHS 800x480 4.3 Inch IPS TFT LCD Display 40 Pin With Touch Screen 24 BIT RGB Interface
RoHS 800x480 4.3 Inch IPS TFT LCD Display 40 Pin With Touch Screen 24 BIT RGB Interface
RoHS 800x480 4.3 Inch IPS TFT LCD Display 40 Pin With Touch Screen 24 BIT RGB Interface
RoHS 800x480 4.3 Inch IPS TFT LCD Display 40 Pin With Touch Screen 24 BIT RGB Interface
RoHS 800x480 4.3 Inch IPS TFT LCD Display 40 Pin With Touch Screen 24 BIT RGB Interface
RoHS 800x480 4.3 Inch IPS TFT LCD Display 40 Pin With Touch Screen 24 BIT RGB Interface
RoHS 800x480 4.3 Inch IPS TFT LCD Display 40 Pin With Touch Screen 24 BIT RGB Interface
RoHS 800x480 4.3 Inch IPS TFT LCD Display 40 Pin With Touch Screen 24 BIT RGB Interface
Specifications
Viewing Angle :
All
Model Number :
KWH043ST42-F01
Place of Origin :
China
Product Name :
800x480 IPS TFT LCD 4.3 Inch Display 40 pin With 24 BIT RGB Interface
Interface :
40 Pin, 24 BIT RGB
Supply Ability :
5000000000 pieces/year
Brand Name :
Formike
MOQ :
1 piece
Packaging Details :
Tray + Inner Box + Carton
Color :
Color
Dimensions :
105.45mm x 67.20mm x 3.00mm
Operating Temperature :
-20°C to 70°C
Display Size :
4.3 inch
Payment Terms :
T/T,L/C,Credit card,Cash
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Touch Screen :
Without (Optional with touch screen)
Technology :
a-Si Technology type, HC Surface Treatment
Resolution :
800 x 480
Display Type :
4.3 Inch TFT LCD Panel
Description

800x480 IPS TFT LCD 4.3 Inch Display 40 pin With 24 BIT RGB Interface

RoHS 800x480 4.3 Inch IPS TFT LCD Display 40 Pin With Touch Screen 24 BIT RGB Interface

LCD Name 800x480 IPS TFT LCD 4.3 Inch Display 40 pin With 24 BIT RGB Interface

LCD Size

4.3 inch LCD Module

Resolution

800(RGB)X480 Resolution

Color Depth

16.7M

Contrast Ratio

800:1

Outline Dimension

105.45x 67.20 x 3.00mm

Active Area(HxV mm)

95.04x53.856mm

Viewing Direction

Free Viewing Angle

Interface

24-bit RGB,40 Pin

Backlight

12 White LEDs

Brightness

400cd/m2

Special Technology

a-Si technology type

HC surface treatment

Backlight Supply Current/Voltage

60mA 3.3V

Operating Temperature

-20℃~70℃

Storage Temperature

-30℃~85℃

* KWH043ST42-F01 is a Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight.

* It is 800x480 resolution TFT LCD module.

* Backlight with different brightness options from 100 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.
