Specifications
Dimensions :
62.36mmx 105.75mm x 2.10mm
Driver IC :
NT35510
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Packaging Details :
Tray + Inner Box + Carton
Product Name :
480x800 WVGA Display 45 Pin LCD 4.3 Screen IPS TFT Module With NT35510 Driver IC
Supply Ability :
5000000000 pieces/year
Display Mode :
IPS TFT
MOQ :
1 piece
Viewing Angle :
All
Place of Origin :
China
Operating Temperature :
-20°C to 70°C
Display Type :
4.3 Inch Display Module
Interface :
45 Pin, 16 BIT RGB
Brand Name :
Formike
Model Number :
KWH043ST40-F01
Payment Terms :
T/T,L/C,Credit card,Cash
Color :
Color
Touch Screen :
Without (Optional with touch screen)
Display Size :
4.3 inch
Resolution :
480x800
Description

480x800 WVGA Display 45 Pin LCD 4.3 Screen IPS TFT Module With NT35510 Driver IC

480x800 WVGA 45 Pin TFT Display LCD Screen 4.3 IPS Module With NT35510 Driver IC

LCD Name 480x800 WVGA Display 45 Pin LCD 4.3 Screen IPS TFT Module With NT35510 Driver IC

LCD Size

4.3 inch IPS LCD Module

Resolution

480(RGB)X800 Resolution

Color Depth

65K

Contrast Ratio

800:1

Outline Dimension

62.36x 105.75 x 2.10mm

Active Area(HxV mm)

56.16x93.60mm

Viewing Direction

Free Viewing Angle

Interface

16-bit RGB,45 Pin

Backlight

8 White LEDs

Brightness

330cd/m2

Drive IC

NT35510

Backlight Supply Current/Voltage

20mA 3.3V

Operating Temperature

-20℃~70℃

Storage Temperature

-30℃~85℃

* KWH043ST40-F01 is a Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight.

* It is 480x800 resolution TFT LCD module.

* Backlight with different brightness options from 100 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.
