Specifications
Brand Name :
Formike
Resolution :
800*480
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Viewing Angle :
All
Display Size :
4.3-inch
Dimensions :
105.45mm x 67.20mm x 3.00mm
Payment Terms :
T/T,L/C,Credit card,Cash
Touch Screen :
Without (Optional with touch screen)
Supply Ability :
5000000000 pieces/year
Product Name :
800x480 TFT 50 Pin LCD Display 4.3 LCD Module With a-Si Technology type and HC Surface Treatment
Technology :
a-Si Technology type, HC Surface Treatment
Packaging Details :
Tray + Inner Box + Carton
Color :
Color
Model Number :
KWH043ST41-F01
Operating Temperature :
-20°C to 70°C
Interface :
50 Pin, 24 BIT RGB
MOQ :
1 piece
Display Type :
4.3 Inch TFT LCD Module
Place of Origin :
China
Description

800x480 TFT 50 Pin LCD Display 4.3 LCD Module With a-Si Technology type and HC Surface Treatment

OEM 50 Pin 800x480 TFT 4.3 Inch LCD Display Module With A-Si Technology

LCD Name 800x480 TFT 50 Pin LCD Display 4.3 LCD Module With a-Si Technology type and HC Surface Treatment

LCD Size

4.3 inch LCD Module

Resolution

800(RGB)X480 Resolution

Color Depth

16.7M

Contrast Ratio

800:1

Outline Dimension

105.45x 67.20 x 3.00mm

Active Area(HxV mm)

95.04x53.856mm

Viewing Direction

Free Viewing Angle

Interface

24-bit RGB,50 Pin

Backlight

12 White LEDs

Brightness

400cd/m2

Special Technology

a-Si technology type

HC surface treatment

Backlight Supply Current/Voltage

60mA 3.3V

Operating Temperature

-20℃~70℃

Storage Temperature

-30℃~85℃

* KWH043ST41-F01 is a small Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight.

* It is 800x480 resolution TFT LCD module.

* Backlight with different brightness options from 100 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.
