TCSUNBOW DDR5 DDR4 RGB Memory Heat Sink Series RH51/RH41
TCSUNBOW DDR5 DDR4 RGB Memory Heat Sink Series RH51/RH41
TCSUNBOW DDR5 DDR4 RGB Memory Heat Sink Series RH51/RH41
TCSUNBOW DDR5 DDR4 RGB Memory Heat Sink Series RH51/RH41
TCSUNBOW DDR5 DDR4 RGB Memory Heat Sink Series RH51/RH41
TCSUNBOW DDR5 DDR4 RGB Memory Heat Sink Series RH51/RH41
TCSUNBOW DDR5 DDR4 RGB Memory Heat Sink Series RH51/RH41
TCSUNBOW DDR5 DDR4 RGB Memory Heat Sink Series RH51/RH41
Specifications
Model Number :
RH51/RH41
Installation Type :
Internal
MOQ :
1
Heat Sink :
Yes
Payment Terms :
L/C,D/P,T/T
RGB Lighting :
Yes
Certification :
RoHS,CE,FCC,ISO
Memory Type :
DDR5 / DDR4 DRAM
Delivery Time :
1-7
Storage Temperature Range :
-40-75℃
Place of Origin :
China
Color :
Black/Silver
Operating Temperature Range :
0-75℃
Brand Name :
TCSUNBOW/TCS
Form Factor :
UDIMM
Description
  • Defined parallel lines run across the heat sink surface, giving the RH51/RH41 a structured appearance rather than a plain, uniform finish.

  • The integrated heat sink adds a functional thermal element to the module while complementing the geometric surface design.

  • RGB lighting gives the memory a more dynamic presence within transparent or open PC cases and can become part of the overall system aesthetic.

  • DDR5 configurations cover 4800MHz, 5600MHz, 6000MHz, and 6400MHz, while DDR4 options include 2400MHz, 2666MHz, 3000MHz, 3200MHz, and 4200MHz.

  • With an operating temperature range of 0°C to 75°C, the RH51/RH41 is specified for use across a range of typical desktop environments.

Series DDR5 RGB With Heatsink UDIMM Series(RH51 Series)
Brand TCSUNBOW
Capacity 8GB 16GB 32GB
Model Number RH51-DDR5-PC-8GB RH51-DDR5-PC-16GB RH51-DDR5-PC-32GB
EAN 6935515143604 6935515143598 6935515143581 6935515143574 6935515143567 6935515143550 6935515143543 6935515143536 6935515143505 6935515143499 6935515143482 6935515143475
Memory Speed / Frequency 4800MHz 5600MHz 6000MHZ 6400MHZ 4800MHz 5600MHz 6000MHZ 6400MHZ 4800MHz 5600MHz 6000MHZ 6400MHZ
Rank (1Rx8/2Rx8/8Rx4) 1Rx8 1Rx8 2Rx8 2Rx8 1Rx8 1Rx8 2Rx8 2Rx8 2Rx8 2Rx8 2Rx8 2Rx8
CAS Latency CL40-40-40-77 CL46-45-45-90 CL46-48-48-96 CL56-56-56-102 CL40-40-40-77 CL46-45-45-90 CL46-48-48-96 CL56-56-56-102 CL40-40-40-77 CL46-45-45-90 CL46-48-48-96 CL56-56-56-102
Operating Voltage 1.1v 1.1v 1.35 1.4v 1.1v 1.1v 1.35 1.4v 1.1v 1.1v 1.35 1.4v
No. of Memory IC 8/16
Power Consumption 3W
Controller IC NO
Overclock Support (YES / NO) NO
ECC (Error Correction Code) (YES/NO) NO
Net Weight (g) 55g
Gross Weight (g) 90g
Pin Count 288
OEM/ODM Support YES
Heat Sink / Heat Spreader YES
RGB lights YES
Form Factor UDIMM
Computer Memory Type (DRAM/SDRAM) DRAM
Operating Temperature 0-70℃
Storage Temperature -40~85℃
Warranty 3 Years
No. of Memory Channels (Single/Dual) (Single/Dual)
Product Dimension (W x D x H) in mm 138x53x6mm
Buffered / Un-buffered Memory Un-buffered Memory
Memory IC Brand Micron/Samsung/Sk Hynix
Note: All specifications and performance data are for reference purposes only. Actual results may vary depending on platform and system configuration. TCSUNBOW/TCS reserves the right of final interpretation.
