Specifications
MOQ :
1 piece
Payment Terms :
T/T, L/C, Credit card, Cash
Display Size :
3.5 inch
Interface :
51 Pin, 8/9 BIT MCU, 16/18/24 BIT RGB
Product Name :
320x480 Display ILI9488 Touch Screen 3.5 Inch LCD Module
Brand Name :
Formike
Operating Temperature :
-20°C to 70°C
Supply Ability :
5000000000 pieces/year
Resolution :
320 x 480
Touch Screen :
With resistive touch screen
Color :
Color
Packaging Details :
Tray + Inner Box + Carton
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Dimensions :
55.04mm x 84.71mm x 3.65mm
Controller Ic :
ILI9488
Display Type :
3.5Inch TFT LCD Screen
Viewing Angle :
12 O'Clock
Model Number :
KWH035ST44-F02
Place of Origin :
China
Supply Voltage :
2.8V
Description

320x480 Display ILI9488 Touch Screen 3.5 Inch LCD Module

RoHS Touch Screen 3.5 Inch TFT Display LCD Module 320x240 ILI9488

Product Name 320x480 Display ILI9488 Touch Screen 3.5 Inch LCD Module
LCD Size 3.2 Inch TFT LCD Display Module With Resistive Touch Screen
Display Mode Transmissive
Resolution 320x480
Outline Dimension (mm) 55.04x84.71x3.65
Active Area (mm) 48.96x73.44
Dot pitch (mm) 0.153x0.153
Viewing Direction 12 O'Clock
Interface MCU/RGB Interface, 51 Pin
Driver IC ILI9488
Brightness (Cd/m2) 250
Contrast Ratio 500:1
Backlight 6 White LED in Parallel

Backlight Supply

(Current/Voltage)

 20mA 19.2V
Touch Screen With Resistive Touch Screen

* KWH035ST44-F02 is a Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight, RTP.

* It is 320x480 resolution TFT LCD module.

* Backlight with different brightness options from 250 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.
