Specifications
Display Size :
7-inch
Resolution :
1024*600
Viewing Angle :
All
Payment Terms :
T/T,L/C,Credit card,Cash
Supply Ability :
5000000000 pieces/year
Interface :
50 Pin, 24 BIT RGB
Product Name :
1024X600 Screen Touch TFT LCD 7 Inch IPS Display With 50pin 24 BIT RGB Interface
Dimensions :
168.15mm x 99.25mm x 4.60mm
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Packaging Details :
Partition + A/S Bag + Corrugated Bar + Carton
Operating Temperature :
-20°C to 70°C
Model Number :
KWH070KQ40-C15
Display Type :
7 Inch IPS TFT LCD Panel
Brand Name :
Formike
Touch Screen :
With capacitive touch panel
Color :
Color
Place of Origin :
China
MOQ :
1 piece
Supply Voltage :
3.3V
Description

1024X600 Screen Touch TFT LCD 7 Inch IPS Display With 50pin 24 BIT RGB Interface

1024X600 TFT LCD IPS 7 Inch Display Touch Screen With 50pin 24 BIT RGB Interface

Product Name 1024X600 Screen Touch TFT LCD 7 Inch IPS Display With 50pin 24 BIT RGB Interface
LCD Size 7 Inch TFT LCD Display Module
Display Mode IPS
Resolution 1024x600
Outline Dimension (mm) 168.15x99.25x4.60
Active Area (mm) 154.21x85.92
Dot pitch (mm) 0.1506x0.1432
Viewing Direction All
Interface RGB Interface, 50 Pin
Driver IC EK79001HB & EK73215BCGA
Brightness (Cd/m2) 350
Contrast Ratio 800:1
Backlight 27 White LED

Backlight Supply

(Current/Voltage)

 180mA 9.9V
Touch Screen With Capacitive Touch Screen Panel

* KWH070KQ40-C15 is a IPS type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight, CTP.

* It is 1024x600 resolution TFT LCD module.

* Backlight with different brightness options from 250 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.
