Specifications
Color :
Color
Product Name :
7 Inch Touch TFT LCD 720X1280 Screen IPS MIPI Display With ILI9881C Driver IC
Packaging Details :
Partition + A/S Bag + Corrugated Bar + Carton
Supply Voltage :
2.8V
Interface :
40 Pin, 4 LANE MIPI
MOQ :
1 piece
Dimensions :
106.59mm x 179.62mm x 4.05mm
Display Type :
7Inch TFT LCD Display
Model Number :
KWH070KQ48-C01
Brand Name :
Formike
Place of Origin :
China
Payment Terms :
T/T,L/C,Credit card,Cash
Operating Temperature :
-20°C to 70°C
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Viewing Angle :
All
Supply Ability :
5000000000 pieces/year
Resolution :
720 x 1280
Display Size :
7"
Touch Screen :
With capacitive touch screen
Description

7 Inch Touch TFT LCD 720X1280 Screen IPS MIPI Display With ILI9881C Driver IC

TFT LCD 7

Product Name 7 Inch Touch TFT LCD 720X1280 Screen IPS MIPI Display With ILI9881C Driver IC
LCD Size 7 Inch TFT LCD Display Module
Display Mode IPS
Resolution 720x1280
Outline Dimension (mm) 106.59x179.62x4.05
Active Area (mm) 86.94x154.56
Dot pitch (mm) 0.12075x0.12075
Viewing Direction All
Interface MIPI Interface, 40 Pin
Driver IC ILI9881C
Brightness (Cd/m2) 300
Contrast Ratio 800:1
Backlight 21 White LED

Backlight Supply

(Current/Voltage)

 60mA 22.4V
Touch Screen With Capacitive Touch Screen Panel

* KWH070KQ48-C01 is a IPS type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight, CTP.

* It is 720x1280 resolution IPS TFT LCD module.

* Backlight with different brightness options from 250 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.

KWH070KQ48-C01: 7" IPS LCD with Capacitive Touch

The KWH070KQ48-C01 is a 7-inch IPS TFT LCD module featuring a 720x1280 resolution. It incorporates a capacitive touch panel for intuitive interaction. This display utilizes a MIPI interface for efficient data transfer. With a bright 300 cd/m2 backlight and a high 800:1 contrast ratio, it delivers clear and vivid visuals. Ideal for applications demanding high image quality and touch functionality.

Applications:

Portable devices: Tablets, e-readers
Consumer electronics: Digital photo frames, GPS navigators
Industrial control: HMI panels, monitoring systems


Need a custom solution? We offer tailored options for backlight brightness, touch panel, and other specifications. Contact us now.
