Specifications
Dimensions :
179.40mm x 117.40mm x 7.37mm
MOQ :
1 piece
Product Name :
50 Pin TFT LCD Pinout 800 X 480 7 Inch Display With Touch Screen
Display Type :
7 Inch TN TFT LCD
Model Number :
KWH070KQ38-C05
Operating Temperature :
-20°C to 70°C
Interface :
50Pin, 24 BIT RGB
Touch Screen :
With capacitive touch panel
Display Size :
7inch
Place of Origin :
China
Color :
Color
Brand Name :
Formike
Resolution :
800 X 480
Supply Voltage :
3.3V
Payment Terms :
T/T,L/C,Credit card,Cash
Supply Ability :
5000000000 pieces/year
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Packaging Details :
Partition + A/S Bag + Corrugated Bar + Carton
Viewing Angle :
6 O'Clock
Description

50 Pin TFT LCD Pinout 800 X 480 7 Inch Display With Touch Screen

Transmissive TFT LCD Pinout Touch 7 Inch Hdmi Screen Display 800 X 480 50 Pin

Product Name 50 Pin TFT LCD Pinout 800 X 480 7 Inch Display With Touch Screen
LCD Size 7 Inch TFT LCD Display Module
Display Mode Transmissive
Surface Treatment Anti-Glare
Driver Element A-Si TFT
Resolution 800x480
Outline Dimension (mm) 179.40x117.40x7.37
Active Area (mm) 154.08x85.92
Dot pitch (mm) 0.0642x0.1790
Viewing Direction 6 O'clock
Interface RGB Interface, 50 Pin
Color Depth 16M
Brightness (Cd/m2) 200
Contrast Ratio 500:1
Backlight 12 White LED

Backlight Supply

(Current/Voltage)

 120mA 9.6V
Touch Screen With Capacitive Touch Screen Panel

* KWH070KQ38-C05 is a Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight, CTP.

* It is 800x480 resolution TFT LCD module.

* Backlight with different brightness options from 250 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.
