Multi Face Zero Point Clamping System Block CNC Workholding Fixture
Multi Face Zero Point Clamping System Block CNC Workholding Fixture
Specifications
Brand Name :
ADJIG
Model Number :
Q9LZ-10/Q9LZ-20
Place of Origin :
Chongqing, China
MOQ :
1
Price :
2903 - 24648 USD per item
Payment Terms :
L/C,T/T
Supply Ability :
Less than 30 pieces, shipped within 5-7 days. More than 30 items will be shipped within 25-30 days.
Delivery Time :
7-10 days
Packaging Details :
Carton/wooden crate
Unlock Method :
Pneumatic Pressure
Repeatability :
＜0.005mm
Clamping Force (KN) :
(3×)3×10/(3×)3×17
Tensile Force (KN) :
(3×)3×25/(3×)3×55
Description

Multi-Face CNC Fixture Block for Zero-Point Positioning Systems CNC Workholding Fixture

Product Features:
Pneumatic unlocking, mechanical locking
Material: HT300
Surface and live pin hardened treatment
Repeat positioning accuracy <0.005MM.
Applicable Industries:
Suitable for metal or non-metal cutting fields
Suitable for horizontal CNC machine tool processing.

Part Number Size Number Unlock Method Clamping Force
(KN)		 Tensile Force
(KN)		 Chip Blowing Weight
(kg)
Q9LZ-10 Q10 Pneumatic Pressure (3×)3×10 (3×)3×25 √ 260
Q9LZ-20 Q20 Pneumatic Pressure (3×)3×17 (3×)3×55 √ 303

Part Number A B C D E F G H I J K
Q9LZ-10 250 224 550 160 152 15 216 12 550 110 24
Q9LZ-20 313 280 688 200 190 19 271 15 688 138 30
