Pneumatic Zero Point Clamping System Stainless Steel Quick-Change
Pneumatic Zero Point Clamping System Stainless Steel Quick-Change
Specifications
Brand Name :
ADJIG
Place of Origin :
Chongqing, China
MOQ :
1
Price :
276 - 1034 USD per item
Payment Terms :
L/C,T/T
Supply Ability :
Less than 30 pieces, shipped within 5-7 days. More than 30 items will be shipped within 25-30 days.
Delivery Time :
7-10 days
Packaging Details :
Carton/wooden crate
Model Number :
ANC
Unlock Method :
Pneumatic Pressure
Clamping Force (KN) :
17
Tensile Force (KN) :
55
Blow :
✔
Weight (kg) :
2.6
Repeatability（mm） :
0.005
Material :
Hardened Stainless Steel
Service Life :
One Million Times
Description

High-Precision Pneumatic Stainless Steel Quick-Change Zero-Point Clamping System

Product Features:
1. Pneumatic unlocking, spring mechanical locking; Material: hardened stainless steel

2. Repeat positioning accuracy <0.005MM
3. Double-sided constraint, high precision
4. Includes a central air blowing interface to prevent iron filings from entering. Applicable Industries
Suitable for the automation industry

Suitable for quick-change fixtures

Part Number Size Number Unlock Method Clamping Force
(KN)		 Tensile Force
(KN)		 Chip Blowing Weight
(kg)
ANCZ-10 Q10 Pneumatic Pressure 10 25 √ 1.4
ANCZ-20 Q20 Pneumatic Pressure 17 55 √ 2.7

Size Number φD1 φD2 φD3 C H H1
(±0.005)		 H2 M E
(H7)		 F
Q10 112 22 13 8.5 40 10 30 M6 78 92
Q20 138 32 18 8.5 53 15 38 M6 102 115
