Precision Four Alignment Pins Quick-Change Fixture Locating Plate for CNC Workholding
Precision Four Alignment Pins Quick-Change Fixture Locating Plate for CNC Workholding
Precision Four Alignment Pins Quick-Change Fixture Locating Plate for CNC Workholding
Precision Four Alignment Pins Quick-Change Fixture Locating Plate for CNC Workholding
Specifications
Brand Name :
ADJIG
Model Number :
4GWTP
Place of Origin :
Chongqing, China
MOQ :
1
Price :
345 - 741 USD per item
Payment Terms :
L/C,T/T
Supply Ability :
Less than 10 pieces, shipped within 10 days. More than 10 items will be shipped within 30 days.
Delivery Time :
7-10 days
Packaging Details :
Carton/wooden crate
Material :
P20 or aluminum alloy (customizable)
Scope of Application :
Zero point dedicated for four units
Repeatability（mm） :
<0.005
Long(mm) :
200/366/398/426
Wide(mm) :
200/366/398/426
Spacing(mm) :
100/200/200/200
Description

Precision Four Alignment Pins Quick-Change Fixture Locating Plate for CNC Workholding


This Precision Quick-Change Fixture Locating Plate, equipped with four hardened alignment pins, delivers unmatched accuracy and stability for CNC workholding. The quadruple-pin configuration ensures perfect, repeatable positioning, eliminating cumulative errors and providing superior resistance to machining forces. Engineered for rapid, tool-less changes, it slashes setup time to seconds while maintaining micron-level repeatability. The robust construction guarantees vibration-free performance during high-speed machining. Ideal for high-mix production and complex multi-operation parts, this system dramatically increases spindle utilization and throughput, making it an essential solution for manufacturers seeking to optimize precision and efficiency in their machining processes.


Part Number Size Number A B SM SM1 T
4GWTP-5 Q5 200 200 100 100 20
4GWTP-10 Q10 366 366 200 200 28
4GWTP-20 Q20 398 398 200 200 28
4GWTP-40 Q40 426 426 200 200 38
