Precision Quick-Change Fixture Locating Plate With Dual Alignment Pins For CNC Workholding
Precision Quick-Change Fixture Locating Plate With Dual Alignment Pins For CNC Workholding
Specifications
Brand Name :
ADJIG
Model Number :
2GWTP
Place of Origin :
Chongqing, China
MOQ :
1
Price :
179 - 352 USD per item
Payment Terms :
L/C,T/T
Supply Ability :
Less than 10 pieces, shipped within 10 days. More than 10 items will be shipped within 30 days.
Delivery Time :
7-10 days
Packaging Details :
Carton/wooden crate
Material :
Stainless steel
Repeatability（mm） :
<0.005
Application :
Two-unit zero-point positioning base plate
Long(mm) :
200/366/398
Wide(mm) :
100/166/198
Spacing(mm) :
100/200/200
Description

Precision Quick-Change Fixture Locating Plate with Dual Alignment Pins for CNC Workholding

Repeat positioning accuracy:<0.005mm

Material: Die steel

This Precision Quick-Change Fixture Locating Plate revolutionizes CNC workholding efficiency. Featuring dual hardened alignment pins for flawless, repeatable positioning, it enables tool-less fixture changes in seconds. Achieve micron-level accuracy and eliminate manual re-zeroing with every swap. The robust design ensures maximum rigidity, minimizing vibration during high-speed machining. Ideal for high-mix production, this system dramatically reduces downtime between jobs, boosting spindle utilization and overall productivity. Engineered for seamless integration with existing setups, it provides a reliable foundation for complex machining operations, delivering unparalleled speed and precision in your manufacturing workflow.

Part Number Size Number A B SM T
2GWTP-5 Q5 200 100 100 20
2GWTP-10 Q10 366 166 200 28
2GWTP-20 Q20 398 198 200 28
2GWTP-40 Q40 426 226 200 38
