30V Robot Wire and Cable UL20549 4P×0.34mm2 Tinned Copper Stranded
30V Robot Wire and Cable UL20549 4P×0.34mm2 Tinned Copper Stranded
30V Robot Wire and Cable UL20549 4P×0.34mm2 Tinned Copper Stranded
30V Robot Wire and Cable UL20549 4P×0.34mm2 Tinned Copper Stranded
Specifications
MOQ :
1000m
Delivery Time :
3-4 Weeks
Voltage :
30V
SP :
1605724
Certification :
RoHS Reach
Insulation :
PVC
Model Number :
UL20549
Conductor :
Tinned Copper Stranded
Supply Ability :
100km per day
Packing :
Packed in Rolls or Reels
Brand Name :
Shineplus
Name :
Robot Wire and Cable
Payment Terms :
T/T,L/C,Western Union
Application :
Robot Manipulator
Price :
To be negotiated
Temperature :
-20~80℃
Place of Origin :
China
Jacket :
TPU
Packaging Details :
Packed in rolls or reels
Description

UL20549 4P×0.34mm2 Robot Cable Tinned Copper Stranded with PVC Insulation and TPU Jacket 30V

ITEM 4P×0.34mm2(65/0.08T)+WB
CONDUCTOR Material Tinned copper stranded
Size 65/0.08mm+nylon
O.D.(Ref) 0.76mm
INSULATION Material PVC
Min.average thickness 0.38mm
Min.thickness at any point 0.33mm
O.D. 1.60±0.10mm
TWIST O.D. 3.20mm
CABLING Filler Cotton
Material Non-woven tape , overlapping: 25% min.
BRAID Material Tinned copper
Size 16/12/0.10mm , 80﹪ Min.
SEPARATOR Material Paper , overlapping : 25% min.
JACKET Material TPU
Min.average thickness 1.00mm
Min.thickness at any point 0.80mm
O.D. 9.30±0.30mm

Application:For internal wires of industrial control equipment and robot manipulators

This product is suitable for high speed drag chain, bending and high strength applications such as miniaturized linear motors.

Electric Performance:

Rated Temperature:-20~80℃

Voltage rating:300V

Max.conductor DC resistance(20℃):59.4Ω/km

Voltage withstand test:AC 0.5kV/1min

Min.Insulation resistance(20℃):100MΩ.km

Mechanical Performance:

Tensile strength:≥10.3MPa

Elongation:≥100%

Aged condition:113±1℃×168h

Percent of original tensile strength:≥70%

Percent of original elongation:≥65%

Torsion test:±90º,bending:90º,20~30cycles/min.,
Length:3inch ≥50,000 cycles No broken
Bending test:±90°,R=5*OD ,Load:500g
20~30cycles/min,≥50,000cycles
Min. bending radius:7*OD(insulation)
