Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Model NO. :
CLW9100ZXD
MOQ :
1
Price :
15000-35000 per unit
Maximum Lifting Height :
15-20m
Crane Jib :
Five-Arm
Gearbox :
10forwards and 2 Reverse
Specification :
80T 100T 120T 150T
Trademark :
CLW
Transport Package :
Naked, Waxed, Bulk Ship, RO-RO
Shaft Number :
5
Chassis Brand :
Sinotruk HOWO/Camc
Working Radius :
15.0m
Cargo Materia :
Q345 Carbon Steel
Production Capacity :
100
Crane Brand :
Palfinger, Clw, etc.
Crane Capacity :
80t 100t 120t 150t
Max. Lifting Height :
16.8m
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
HS Code :
8705909990
Driving Model :
LHD, Rhd
Name :
Truck Mounted Crane
Boom Type :
Knuckle Boom
Turning Angle :
360 Degree
Condition :
New
Crane Boom Type :
Knuckle Crane
Type :
Straight Arm
Origin :
Suizhou, China
Maximum Lifting Weight :
80t 100t 120t 150t
Description
HOWO China Quality Heavy Duty 100ton Truck Crane 120tons Truck Mounted Crane Lorry-Mounted Crane
Product Description

1.Truck crane, referred to as crane truck (crane truck), is a hydraulic lift and telescopic system to achieve the goods up and down, rotary, lifting equipment, usually assembled on the truck.
2.Generally by the truck chassis, cargo compartment, take power, crane composition. Truck chassis optional Dongfeng, liberation, Auman, Steyr, Tang Jun and other tonnage. According to the manufacturers can be divided into Wuyi truck crane, the new Flying, iron, Xugong, Hongchang Tianma, Jianghuan, Yutong Heavy Industry, Feitao, stone coal, according to the type of crane is divided into straight arm and folding arm , According to tonnage is divided into 2 tons, 3.2 tons, 4 tons, 5 tons, 6.3 tons, 8 tons, 10 tons, 12 tons, 16 tons, 20 tons.
3.The arm of the truck is divided into a straight arm with a crane and a folding arm. In general, the folding arm crane is more expensive than the tonnage straight arm. The advantages of the truck crane is good mobility, rapid transfer, you can set hoisting and transport functions in one, improve resource utilization, the price is much cheaper than the car hanging. The disadvantage is that the work should be out of the legs, nor suitable for a larger slope, soft or muddy field work, lifting performance than the car hanging. Truck crane can be loaded with all kinds of grasping aids, such as wood grab grab [1], basket, clip brick fixture, drilling tools, etc., to achieve multi-scene operations. Trolley crane because of its flexible and more features, the market is optimistic, the future market potential.
4.Brand recommendation:DF FOTON JAC HOWO SINOTRUK SHACMAN ,Tonnage:1T-22T customized

Specification
ConditionNew condition/Left hand drive/10x4











Chassis

BrandSINOTRUK
ModelHOWO
Curb weight(kg)49870 kg
Wheelbase(mm)1950+3075+1375+1350 mm
Dimensions(mm)11500×2500×3980 mm
Overhang (front/rear) (mm)1500/2250 mm
Approach/Departure angle(°)14/12
Axle Load(kg)8000/8000/8000/13000/13000 kg
Max. driving speed(km/h)80 km/h
ClutchReinforced diaphragm clutch
BrakesService brake: dual circuit compressed air brake. Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust valve brake
Steering GearZF, Power steering, hydraulic steering with power assistance
TireNumber14pcs with one spare tire
Specifications12.00R20
Transmission10 Forwards and 2 Reverses
CabinIt can accommodate three people, With Air conditioner



Engine

BrandSINOTRUK
ModelD10.38-50
Displacement(ml)9726 ml
Power(kw)/Horsepower/(HP)276 kw/380 HP
Emission standardEuro 5
Upper




Crane

Working Platform360°turning(left or right), H-shape legs 360°
Extendable boom section6
Boom TypeStraight type
Max. Lifting Weight(tons)100 tons
Max. Working Radius(m)15.0 m
Max. Lifting height(m)16.8 m
