Specifications
Place of Origin :
CHINA
Brand Name :
CLW
Max Lifting Height :
12.8m
HS Code :
8705909990
Model NO. :
CLW5074XW
Maximum Lifting Height :
20-25m
Certification :
ISO9001
MOQ :
1
Price :
15000-35000 per unit
Gearbox :
Fast, 6forwards & 1reverse
Crane Jib :
Five-Arm
Crane Brand :
Clw, etc.
Specification :
11950*2500*3850 mm
Crane Boom Type :
Straight Telescopic Crane, Knuckle Crane
Crane Weight :
2050kg
Installation Space :
900mm
Name :
Truck Mounted Crane
Crane Capacity :
6.3ton, 8ton, 10ton, 12ton, 14ton, 16ton, etc.
Max. Lifting Capacity :
6300 Kg
Shaft Number :
2
Type :
Folding
Chassis Brand :
Dongfeng, Sinotruk HOWO, Foton, FAW, JAC, Jmc, Isu
Origin :
Suizhou, China
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Cargo Material :
Q235 Carbon Steel
Working Radius :
11m
Production Capacity :
500 Unit/Month
Maximum Lifting Weight :
8-10t
Trademark :
CLW
Cargo Thickness :
Side 1.5mm, Bottom 2.5mm
Transport Package :
Naked, Waxed, Bulk Ship, RO-RO
Engine Brand :
Cummin-S, 190HP
Condition :
New
Boom Type :
Straight 4-Arm Telescopic Boom
Description
HOWO/DONGFENG/ISUZU Mobile Crane 6tons Telescopic Boom Truck Mounted Crane Construction Crane Truck With Drill Drill Pipe
Product Description
  • Crane Brand: Chinese Famous Brand
  • Heavy Duty Cargo box.
  • H Shape Hydraulic front & Rear Leg for safety.
  • Folded Arm & Telescopic Straight Arm Crane for option.
  • Crane capacity: 2ton,2.5ton,3.2ton,4ton,5ton,6.3ton,8ton,10ton,12ton, 14ton,16ton,20ton,25ton
Product Parameters
Truck with Crane
Overview
Name Truck with Crane
Dimension(LxWxH) 6550X2490X2900(mm)
Total Mass 22200 Kg
Rated Payload 15000 Kg
Kerb Weight 7200 Kg
Passenger 3
Appr/Dep Angle 33/22
The Parameters of Chassis
Manufacture/Model Dongfeng/EQ1160GKJ1
Driving Type 4*2 left hand drive
Wheel Base 4500 mm
Gearbox Eight speed forward and one reverse, manual
Front/Rear Track 1900/1800(mm)
Tyre 10.00R20
The Number of Tyre 6+1(spare tyre)
Front/Rear Suspension 1250/2300(mm)
Leaf Spring Number 8/11+8
The Paremeters of Engine
Manufacturer/Model Cummin-s/B190 40
Rated Power 190hp/140kw
Fuel Type Diesel
Displacement/Capacity 5900ml
Emission Standard Euro 3
Cylinder Straight/6/intercooling
Max. Torque 560N.m
Velocity 2500rpm
