Isuzu Giga Hino 700 4X2 Folding Arm Crane 8 Tons Truck Mounted
Isuzu Giga Hino 700 4X2 Folding Arm Crane 8 Tons Truck Mounted
Isuzu Giga Hino 700 4X2 Folding Arm Crane 8 Tons Truck Mounted
Isuzu Giga Hino 700 4X2 Folding Arm Crane 8 Tons Truck Mounted
Isuzu Giga Hino 700 4X2 Folding Arm Crane 8 Tons Truck Mounted
Isuzu Giga Hino 700 4X2 Folding Arm Crane 8 Tons Truck Mounted
Isuzu Giga Hino 700 4X2 Folding Arm Crane 8 Tons Truck Mounted
Isuzu Giga Hino 700 4X2 Folding Arm Crane 8 Tons Truck Mounted
Isuzu Giga Hino 700 4X2 Folding Arm Crane 8 Tons Truck Mounted
Isuzu Giga Hino 700 4X2 Folding Arm Crane 8 Tons Truck Mounted
Isuzu Giga Hino 700 4X2 Folding Arm Crane 8 Tons Truck Mounted
Isuzu Giga Hino 700 4X2 Folding Arm Crane 8 Tons Truck Mounted
Specifications
Maximum Lifting Height :
15-20m
HS Code :
8705909990
Place of Origin :
CHINA
Brand Name :
CLW
Crane Boom Type :
Straight Telescopic Crane, Knuckle Crane
Crane Jib :
Four-Arm
Type :
Straight Arm
Cargo Material :
Q235 Carbon Steel
Crane Capacity :
5ton, 6ton, 8ton, 9ton, 10ton, etc.
Gearbox :
8forwards & 1reverse
Crane Brand :
Xc Mg, Clw, etc.
Transport Package :
Naked, Waxed, Bulk Ship, RO-RO
Chassis Brand :
Dongfeng, Sinotruk HOWO, Foton, FAW, JAC, Jmc, Isu
Cargo Thickness :
Side 1.5mm, Bottom 2.5mm
Certification :
GS, RoHS, CE, ISO9001
MOQ :
1
Price :
15000-35000 per unit
Maximum Lifting Weight :
5-7t
Shaft Number :
2
Engine Brand :
Yuchai, 180HP
Trademark :
CLW
Origin :
Suizhou, China
Name :
Truck Mounted Crane
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Model NO. :
CLW5089SCD
Condition :
New
Boom Type :
Straight 4-Arm Telescopic Boom
Specification :
5ton, 6ton, 8ton, 9ton
Production Capacity :
500 Unit/Month
Description
ISUZU GIGA HINO 700 4X2 Folding arm crane 8 tons Truck Mounted with Telescopic Boom Crane truck
Product Description

It's used for lifting and transporting all kinds of bulk cargo, and also applied in jetty and construction work.

Main parts: Crane. (Different lifting capacities match different chassis.)

Advantage: One truck combines the functions of crane and dump truck.

Product Specification
General Technical Parameters
Overall Dimension 9000×2500×3850 (mm)
Gross Vehicle Weight 18500(Kg)
Curb Weight 11380(Kg)
Chassis Specification
Chassis Brand -
Drive model 4*2
Cabin Double, Left Hand Driving, with air conditional
Number of Passengers 3




Engine

 Model 4-stroke direct injection , 6-cylinder in-line with water cooling, inter-cooling, EGR
Power 132KW/180HP
Emission standard EURO 3
Displacement 6500(ml)
Fuel type Diesel
Gearbox 8Forwards & 1Reverse
Brake System Air break
Wheel Base 5100mm
Front/Rear Axle Loading 8000/11500(Kg)
Approach/Departure Angle 23/12(°)
Overhang 1250/3545(mm)
Tire 11.00R20
Max Driving Speed 90(km/h)
