Dongfeng Heavy Duty 10 Wheels Truck Mounted Hydraulic Crane 6*4
Dongfeng Heavy Duty 10 Wheels Truck Mounted Hydraulic Crane 6*4
Dongfeng Heavy Duty 10 Wheels Truck Mounted Hydraulic Crane 6*4
Dongfeng Heavy Duty 10 Wheels Truck Mounted Hydraulic Crane 6*4
Dongfeng Heavy Duty 10 Wheels Truck Mounted Hydraulic Crane 6*4
Dongfeng Heavy Duty 10 Wheels Truck Mounted Hydraulic Crane 6*4
Dongfeng Heavy Duty 10 Wheels Truck Mounted Hydraulic Crane 6*4
Dongfeng Heavy Duty 10 Wheels Truck Mounted Hydraulic Crane 6*4
Dongfeng Heavy Duty 10 Wheels Truck Mounted Hydraulic Crane 6*4
Dongfeng Heavy Duty 10 Wheels Truck Mounted Hydraulic Crane 6*4
Specifications
Type :
Straight Arm
Model NO. :
CLW5205K3MWY
Place of Origin :
CHINA
Brand Name :
CLW
Shaft Number :
3
Crane Jib :
Four-Arm
Chassis :
Dongfeng, Foton, HOWO, etc.
Origin :
Suizhou, China
Name :
Truck Mounted Hydraulic Crane
Working Radius :
13m
Transport Package :
Naked, Waxed, Bulk Ship, RO-RO
Delivery Time :
30 Days
Crane Weight :
4316kg
Color and Logo :
Customized
Production Capacity :
500 Unit/Month
HS Code :
8704224000
Specification :
11900*2500*3850mm
Crane Rotation Angle :
360 Degree
Gearbox :
Manual
Max. Lifting Capacity :
12tons
Trademark :
CLW
Flatbed Dimensions :
8450*2300*550mm
Model Number :
CLW
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
10unit per month
Condition :
New
Max Lifting Height :
15m
MOQ :
1
Price :
15000-35000 per unit
Maximum Lifting Height :
10-15m
Maximum Lifting Weight :
11-13t
Description
China Truck Dongfeng 6*4 Heavy Duty 10 Wheels Hydraulic Crane Lifting Crane Machine Truck Mounted Lifting Crane
Description:
  • Crane Brand: Chinese Famous Brand
  • Heavy Duty Cargo box.
  • H Shape Hydraulic front & Rear Leg for safety.
  • Folded Arm & Telescopic Straight Arm Crane for option.
  • Crane capacity of truck mounted 12t telescopic boom crane:2ton,2.5ton,3.2ton,4ton,5ton,6.3ton,8ton,10ton,12ton, 14ton,16ton,20ton,25ton
General Technical Parameters
Overall Dimension 11900x2500x3850 (mm)
Gross Vehicle Weight 25000kg
Curb Weight 15000kg
Chassis Specification

Chassis Parameters

 Chassis Brand Dongfeng
Cabin Left Hand Driving, with A/C
ABS System Equipped

Engine

 Model 6 Cylinders
Power 210hp
Emission standard EURO V
Displacement 6.7L
Fuel type Diesel
Gearbox 9 Forward & 1 Reverse Gear
Front and Rear Axle load 7T/10T
Wheel base 5700+1300(mm)
Overhang( Front/Rear) 1460/2350(mm)
Angle(Approach/departure) 20/16(°)
Brake System Air Brake
Steering Gear Power Assistant
Tire 11.00R20, 10 Pieces with 1 Spare Tire
Maximum speed 90(km/h)
Superstructure
Flatbed Flatbed dimensions 8450x2300x550(mm)

Working System

Crane

 Brand Chinese Famous Brand
Boom Type Telescopic Boom
Max lifting weight 12,000(kg)
Max lifting height 15(m)
Max working range 13(m)
Rotation angle 360 degree full rotation
Crane Weight 4361kg
Installation space 1150(mm)
Outrigger 2 pcs, Front leg
Operation Hydraulic control, with Aerial Seat
Optional Parts 1. Remote control
2. Rear leg
