Ruggedized Mini DisplayPort connection system Amphenol MDPFTV7BPEGF312 with Tri Start Thread coupling
Ruggedized Mini DisplayPort connection system Amphenol MDPFTV7BPEGF312 with Tri Start Thread coupling
Ruggedized Mini DisplayPort connection system Amphenol MDPFTV7BPEGF312 with Tri Start Thread coupling
Ruggedized Mini DisplayPort connection system Amphenol MDPFTV7BPEGF312 with Tri Start Thread coupling
Specifications
Description :
USB, DVI, HDMI Connector Adapters
Mfr. Part # :
MDPFTV7BPEGF312
Model Number :
MDPFTV7BPEGF312
Description

Product Overview

The Amphenol Socapex MDP FTV is a complete, ruggedized Mini DisplayPort connection system designed for harsh environments. It features a Tri-Start Thread coupling mechanism (MIL-DTL-38999 series III type) for secure mating and offers a robust solution for data acquisition and transmission. The system protects standard Mini DP cordsets from shocks, dust, and fluids, with tool-free assembly in the field. The panel-mount receptacle reinforces and shields the system against leakage, shocks, and vibrations. Ideal for demanding applications in C4ISR, Battlefield, Ground Vehicles, Navy, and Railway sectors.

Product Attributes

  • Brand: Amphenol Socapex
  • Coupling Mechanism: Tri Start Thread (MIL-DTL-38999 series III type)
  • Environmental Protection: Sealed against fluids and dusts (IP68 mated)
  • Compliance: RoHS compliant, EN45545 + UL94V0 (Fire retardant/Low smoke)
  • Origin: Designed by Amphenol Socapex

Technical Specifications

Specification Details
Shell Size 13
Mating Cycles 500 minimum
Panel Thickness (Jam Nut Receptacle) 1.6 mm minimum and 3.18 mm maximum
Data Transmission Protocol Display 1.4
Transmission Bandwidth 32.4 Gbit/s (8.1 Gbit/s per lane)
Resolution Support 8K UHD (7680 4320) at 60 Hz or 4K UHD (3840 2160) at 120 Hz
Salt Spray Resistance (Aluminium Shell) Nickel plating: 48h
Black zinc nickel plating: 500h
Olive drab cadmium plating: 500h
Vibrations 10 - 500 Hz, 10 g, 3 axes: no discontinuity > 10 micro s
Shocks IK06 (weight of 250 g drop from 40 cm onto connectors)
Humidity 21 days, 43C, 98% humidity
Temperature Range -40C / +85C
Plug without cordset Shell type 6
Receptacle Shell type 7 (Reduced flange, Jam nut receptacle)
Receptacle Shell type (with metal backshell) 7PE (Reduced flange jam nut receptacle)
Cordset Lengths 1 m, 1.50 m, 2 m
Accessory Cap Type Standard protective cap
Accessory Chain Length 127 (+13,-7) mm (for MDPFTV C 2 & C 7)
1605 mm (for MDPFTV C 6)
