HH HDMI GD0002 2.1 board mounted dual row connector ideal for front insertion and back stick mounting
HH HDMI GD0002 2.1 board mounted dual row connector ideal for front insertion and back stick mounting
Specifications
Description :
SMD USB, DVI, HDMI Connector Adapters RoHS
Mfr. Part # :
HDMI-GD0002-2.1
Package :
SMD
Model Number :
HDMI-GD0002-2.1
Description

Product Overview

This product is a dual-row, board-mounted connector designed for front-insertion and back-stick applications. It adheres to RoHS standards and is suitable for various internal business and production processes including document distribution, material management, and manufacturing operations like stamping, injection molding, and engineering. The product is manufactured by Shenzhen Huihuan Technology Co., Ltd.

Product Attributes

  • Mounting Type: Board-mounted
  • Configuration: Dual Row
  • Application: Front Insertion, Back Stick
  • Compliance: RoHS
  • Origin: Shenzhen, China
  • Manufacturer: Shenzhen Huihuan Technology Co., Ltd.

Technical Specifications

Model Dimension 1 (mm) Dimension 2 (mm) Dimension 3 (mm) Dimension 4 (mm) Dimension 5 (mm) Dimension 6 (mm) Dimension 7 (mm) Dimension 8 (mm) Dimension 9 (mm) Dimension 10 (mm) Dimension 11 (mm) Dimension 12 (mm) Dimension 13 (mm) Dimension 14 (mm) Dimension 15 (mm) Dimension 16 (mm) Dimension 17 (mm)
HDMI-GD0002-2.1 3.00 5.20 6.50 5.00 5.90 0.03 0.60 0.03 2.30 0.03 6.20 0.30 0.03 3.20 3.60 0.40 19-0.15 0.03 0.20 7.50 2.40 2-1.20
HDMI-GD0002-2.1 0.10 3.00 3.37 2.40 2-1.00

Note: ECN20250522001 dated 2025-05-22 indicates additions of Mylar, bumps, and shell riveting diagrams.
