Honeysuckle Customize Mesh Belt Continuous Dryer Equipment
Honeysuckle Customize Mesh Belt Continuous Dryer Equipment
Honeysuckle Customize Mesh Belt Continuous Dryer Equipment
Honeysuckle Customize Mesh Belt Continuous Dryer Equipment
Honeysuckle Customize Mesh Belt Continuous Dryer Equipment
Honeysuckle Customize Mesh Belt Continuous Dryer Equipment
Honeysuckle Customize Mesh Belt Continuous Dryer Equipment
Honeysuckle Customize Mesh Belt Continuous Dryer Equipment
Specifications
Brand Name :
HengShou
Certification :
ISO SGS
Place of Origin :
Sichuan
MOQ :
1
Price :
$19900-39900 Sets
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Sets Years
Delivery Time :
10 Work Days
Product name :
Honeysuckle Belt Drying Equipment
Product Features :
Dehydration Drying
Field of application :
Food, medicine and chemical industry
Structural form multilayer tape :
multilayer tape
Weight :
2200kg
Description

Honeysuckle Customize Mesh Belt Continuous Dryer Equipment

Description:

Automatic mesh belt dryer is a batch, continuous production of drying equipment, mainly used for dehydrated vegetable processing, pepper drying, Chinese herbal medicine drying, fungus drying, wolfberry drying, tremella drying, agaric drying, longan drying, dried small shrimps, prawns, dried fish potato chips and other products in the drying.

Honeysuckle Customize Mesh Belt Continuous Dryer Equipment

Specifications:

Model DW2×6m DW2×8m DW2×10m DW2×12m DW2×14m DW2×16m
Area of dry 3 layers 29㎡ 40㎡ 51㎡ 62㎡ 73㎡ 83㎡
4 layers 39㎡ 53㎡ 68㎡ 83㎡ 97㎡ 110㎡
5 layers 48㎡ 66㎡ 85㎡ 103㎡ 121㎡ 138㎡
6layers 57㎡ 79㎡ 102㎡ 124㎡ 145㎡ 165㎡
Thickness of the material 50---150mm
Operation temperature 40---120℃
Drying time 0.5——5 hour or 3——15 hour
Motor power 1.1kw 1.5kw 1.5kw 1.5kw 2.2kw 3kw
Evaporation,capacity 200-400kg/h 300-600kg/h 400-700kg/h 500-800kg/h 600-1000kg/h 700-1200kg/h
Size of hot blast stove 1.2×2.5×1.7 1.2×2.7×1.9 1.3×3×2 1.3×3×3 1.6×3.5×2.2 1.6×3.7×2.2
Fan 8C-15kw 10C-15kw 10C-22kw 10C-37kw 12C-30kw 12C-45kw
Output conveyor 1.1kw
Total power 18kw 18.4kw 26kw 41kw 35.1kw 46.7kw

MATERIAL APPLICATION

Honeysuckle Customize Mesh Belt Continuous Dryer Equipment

COMPANY PROFILE

Honeysuckle Customize Mesh Belt Continuous Dryer Equipment

PATENT CERTIFICATE

Honeysuckle Customize Mesh Belt Continuous Dryer Equipment

SHIPMENT AND PACKGAGE

Packaging And Delivery Details:

1. Standard import and export wooden case

2. According to customer requirements, the packaging method can be negotiated.

Honeysuckle Customize Mesh Belt Continuous Dryer Equipment
