Specifications
Brand Name :
HengShou
Certification :
ISO SGS
Place of Origin :
Sichuan
MOQ :
1
Price :
$19900-39900 Sets
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Sets Years
Delivery Time :
10 Work Days
Product name :
Dates Belt Drying Equipment
Drying temperature :
40-100℃
Type of drying :
Dates
Uses :
Food factory
Mesh belt layers :
4-12 layers (can be customized)
Heating source :
water or hot oil,diesel,biomass
Description

Multi Layer Circulating Hot Air Heating Dates Belt Drying Equipment

Quick Detail:

  • Multilayer flipped structure
  • Excellent craftsmanship
  • Adequate protection of food quality

Description:

  1. The drying box is a multi-layer structure, which is cyclically turned over and dried layer by layer, simulating artificial turning under the sun as much as possible. The items in the multi-layer tumble drying box are dehydrated and dried layer by layer, the wet air is directly evacuated from the top layer, and the contact time between the wet air and the item is extremely short (less than 5 seconds), avoiding the occurrence of the fusion of the wet air and the material. The "retting" phenomenon ensures the color of the item.

  2. Excellent concept and production process, high degree of automation, in the temperature of the dryer, fan, moisture removal, walking speed, drying time, PLC control, reduce labor, and increase output.

Multilayer Dates Belt Drying Equipment PLC Control Circulating Hot Air Heating

Specifications:

Model DW2×6m DW2×8m DW2×10m DW2×12m DW2×14m DW2×16m
Area of dry 3 layers 29㎡ 40㎡ 51㎡ 62㎡ 73㎡ 83㎡
4 layers 39㎡ 53㎡ 68㎡ 83㎡ 97㎡ 110㎡
5 layers 48㎡ 66㎡ 85㎡ 103㎡ 121㎡ 138㎡
6layers 57㎡ 79㎡ 102㎡ 124㎡ 145㎡ 165㎡
Thickness of the material 50---150mm
Operation temperature 40---120℃
Drying time 0.5——5 hour or 3——15 hour
Motor power 1.1kw 1.5kw 1.5kw 1.5kw 2.2kw 3kw
Evaporation,capacity 200-400kg/h 300-600kg/h 400-700kg/h 500-800kg/h 600-1000kg/h 700-1200kg/h
Size of hot blast stove 1.2×2.5×1.7 1.2×2.7×1.9 1.3×3×2 1.3×3×3 1.6×3.5×2.2 1.6×3.7×2.2
Fan 8C-15kw 10C-15kw 10C-22kw 10C-37kw 12C-30kw 12C-45kw
Output conveyor 1.1kw
Total power 18kw 18.4kw 26kw 41kw 35.1kw 46.7kw

MATERIAL APPLICATION

Multilayer Dates Belt Drying Equipment PLC Control Circulating Hot Air Heating

COMPANY PROFILE

Multilayer Dates Belt Drying Equipment PLC Control Circulating Hot Air Heating

PATENT CERTIFICATE

Multilayer Dates Belt Drying Equipment PLC Control Circulating Hot Air Heating

SHIPMENT AND PACKGAGE

Packaging And Delivery Details:

1. Standard import and export wooden case

2. According to customer requirements, the packaging method can be negotiated.

Multilayer Dates Belt Drying Equipment PLC Control Circulating Hot Air Heating
