Dryer Large Continuous Belt Drying Equipment Multi Layer Sealed
Dryer Large Continuous Belt Drying Equipment Multi Layer Sealed
Dryer Large Continuous Belt Drying Equipment Multi Layer Sealed
Dryer Large Continuous Belt Drying Equipment Multi Layer Sealed
Dryer Large Continuous Belt Drying Equipment Multi Layer Sealed
Dryer Large Continuous Belt Drying Equipment Multi Layer Sealed
Dryer Large Continuous Belt Drying Equipment Multi Layer Sealed
Dryer Large Continuous Belt Drying Equipment Multi Layer Sealed
Specifications
Brand Name :
ShouKe
Certification :
ISO SGS
Place of Origin :
Sichuan
MOQ :
1
Price :
$19900-39900 Sets
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Sets Years
Delivery Time :
10 Work Days
Product name :
Continuous Belt Drying Equipment
Product Features :
Dehydration
Field of application :
chemical industry
Structural form multilayer tape :
multilayer tape
Weight :
1600kg
Drying time :
0.2-1.2h
Description

Dryer Large Multi-Layer Sealed Continuous Belt Drying Equipment

Description:

Large output: the dryer adopts multi-layer circulation dynamic drying mode, which can dry and process in batches for 24 hours.
High quality: the dried materials are bright in color, complete in shape, rich in taste, and moderate in moisture, which is trusted by users.
Intelligent and accurate: The use of an intelligent control system can ensure the temperature, duration, air volume, and other parameters control during the drying process.

Dryer Large Continuous Belt Drying Equipment Multi Layer Sealed

Specifications:

Model DW2×6m DW2×8m DW2×10m DW2×12m DW2×14m DW2×16m
Area of dry 3 layers 29㎡ 40㎡ 51㎡ 62㎡ 73㎡ 83㎡
4 layers 39㎡ 53㎡ 68㎡ 83㎡ 97㎡ 110㎡
5 layers 48㎡ 66㎡ 85㎡ 103㎡ 121㎡ 138㎡
6layers 57㎡ 79㎡ 102㎡ 124㎡ 145㎡ 165㎡
The thickness of the material 50---150mm
Operation temperature 40---120℃
Drying time 0.5——5 hour or 3——15 hour
Motor power 1.1kw 1.5kw 1.5kw 1.5kw 2.2kw 3kw
Evaporation, capacity 200-400kg/h 300-600kg/h 400-700kg/h 500-800kg/h 600-1000kg/h 700-1200kg/h
Size of hot blast stove 1.2×2.5×1.7 1.2×2.7×1.9 1.3×3×2 1.3×3×3 1.6×3.5×2.2 1.6×3.7×2.2
Fan 8C-15kw 10C-15kw 10C-22kw 10C-37kw 12C-30kw 12C-45kw
Output conveyor 1.1kw
Total power 18kw 18.4kw 26kw 41kw 35.1kw 46.7kw

MATERIAL APPLICATION

Dryer Large Continuous Belt Drying Equipment Multi Layer Sealed

COMPANY PROFILE

Dryer Large Continuous Belt Drying Equipment Multi Layer Sealed

PATENT CERTIFICATE

Dryer Large Continuous Belt Drying Equipment Multi Layer Sealed

SHIPMENT AND PACKGAGE

Packaging And Delivery Details:

1. Standard import and export wooden case

2. According to customer requirements, the packaging method can be negotiated.

Dryer Large Continuous Belt Drying Equipment Multi Layer Sealed
