Personalized Customization Mesh Belt Drying Equipment Reuse And Recycling
Personalized Customization Mesh Belt Drying Equipment Reuse And Recycling
Personalized Customization Mesh Belt Drying Equipment Reuse And Recycling
Personalized Customization Mesh Belt Drying Equipment Reuse And Recycling
Personalized Customization Mesh Belt Drying Equipment Reuse And Recycling
Personalized Customization Mesh Belt Drying Equipment Reuse And Recycling
Personalized Customization Mesh Belt Drying Equipment Reuse And Recycling
Personalized Customization Mesh Belt Drying Equipment Reuse And Recycling
Specifications
Brand Name :
HengShou
Certification :
ISO SGS
Place of Origin :
Sichuan
MOQ :
1
Price :
$19900-39900 Sets
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Sets Years
Delivery Time :
10 Work Days
Product name :
Large Belt Drying Equipment
Number of fans :
2-6
Heat transfer area :
20 square meters
Operating temperature :
40-100℃
Drying output (t/h) :
4-20
Paving thickness :
20-60mm
Description

Personalized Customization Mesh Belt Drying Equipment Reuse And Recycling

Description:

Manufacturers supply reliable quality, high quality, and low price, widely applicable stable operation, quality assurance, and worry-free after-sales.

Excellent materials, beautiful appearance, skillful manufacturing technology, and delicate treatment.


Cost saving, fast drying speed, low energy consumption, cost saving, and good effects.


The fan has a simple structure, convenient installation, labor saving, and stable operation.

Personalized Customization Mesh Belt Drying Equipment Reuse And Recycling

Specifications:

Model DW2×6m DW2×8m DW2×10m DW2×12m DW2×14m DW2×16m
Area of dry 3 layers 29㎡ 40㎡ 51㎡ 62㎡ 73㎡ 83㎡
4 layers 39㎡ 53㎡ 68㎡ 83㎡ 97㎡ 110㎡
5 layers 48㎡ 66㎡ 85㎡ 103㎡ 121㎡ 138㎡
6layers 57㎡ 79㎡ 102㎡ 124㎡ 145㎡ 165㎡
Thickness of the material 50---150mm
Operation temperature 40---120℃
Drying time 0.5——5 hour or 3——15 hour
Motor power 1.1kw 1.5kw 1.5kw 1.5kw 2.2kw 3kw
Evaporation,capacity 200-400kg/h 300-600kg/h 400-700kg/h 500-800kg/h 600-1000kg/h 700-1200kg/h
Size of hot blast stove 1.2×2.5×1.7 1.2×2.7×1.9 1.3×3×2 1.3×3×3 1.6×3.5×2.2 1.6×3.7×2.2
Fan 8C-15kw 10C-15kw 10C-22kw 10C-37kw 12C-30kw 12C-45kw
Output conveyor 1.1kw
Total power 18kw 18.4kw 26kw 41kw 35.1kw 46.7kw

MATERIAL APPLICATION

Personalized Customization Mesh Belt Drying Equipment Reuse And Recycling

COMPANY PROFILE

Personalized Customization Mesh Belt Drying Equipment Reuse And Recycling

PATENT CERTIFICATE

Personalized Customization Mesh Belt Drying Equipment Reuse And Recycling

SHIPMENT AND PACKGAGE

Packaging And Delivery Details:

1. Standard import and export wooden case

2. According to customer requirements, the packaging method can be negotiated.

Personalized Customization Mesh Belt Drying Equipment Reuse And Recycling
