KEYENCE KV-B16XC 16-Point DC Input Expansion Module
KEYENCE KV-B16XC 16-Point DC Input Expansion Module
KEYENCE KV-B16XC 16-Point DC Input Expansion Module
KEYENCE KV-B16XC 16-Point DC Input Expansion Module
Specifications
Model Number :
KV-B16XC
Supply Ability :
100PC
Head Mount :
DIN form B head mount
Special Features :
Integrated TwinCAT 3 runtime environment
Packaging Details :
carton
Operating Temperature :
-25°C to +60°C
Brand Name :
KEYENCE
Indicator :
Power indicator
Price :
negotiate
Measuring Range :
150 mm
Product No :
BSW000R
Payment Terms :
T/T,Alipay,Paypal,XT
Temperature Range :
-25°C To +60°C
Place of Origin :
China
MOQ :
1
Line Voltage :
200 to 600 Volts AC
Description

KEYENCE KV-B16XC 16-Point DC Input Expansion Module


Manufacturer :KEYENCE
Product No. : KV-B16XC

Parameter Specification
Model Number KV-B16XC
Brand Keyence
Series KV Modular Programmable Controller
Module Type Digital DC Input Expansion Unit
Number of Input Channels 16 Points
Input Mode Switchable: 24 VDC Mode / 5 VDC Mode
Maximum Rated Input Voltage 26.4 VDC
24 VDC Mode Rating 24 VDC, 5.3 mA
5 VDC Mode Rating 5 VDC, 1 mA
Minimum ON Voltage 19 V (24 VDC mode); 3.5 V (5 VDC mode)
Maximum OFF Threshold 1.5 mA (24 VDC mode); 1.5 V (5 VDC mode)
Input Impedance 4.3 kΩ
Input Time Constant Options 25 µs / 300 µs / 1 ms / 10 ms (4-stage switchable)
Common Point Configuration 16 points / 1 common point (2 terminals, internally connected)
Internal Current Consumption ≤ 15 mA


Parameter Specification
External Wiring Interface Detachable Screw Terminal Block
Mounting Method Standard 35 mm DIN rail mounting
Operating Ambient Temperature 0 °C ~ +55 °C
Storage Temperature Range -20 °C ~ +75 °C
Allowable Humidity 35 % ~ 85 % RH, non-condensing
Protection Class IP20 (for cabinet installation)
Approximate Net Weight 120 g
Compatible Main Units KV-7500 / KV-7300 / KV-5500 / KV-5000 / KV-3000 Series CPU
Vibration Resistance 10–150 Hz, 0.5 mm amplitude, IEC 60068-2-6
Shock Resistance 100 m/s², IEC 60068-2-27
Compliance Certifications CE, UL, CSA
Compliance Standard RoHS


KEYENCE KV-B16XC 16-Point DC Input Expansion Module

Brand


KEYENCE KV-B16XC 16-Point DC Input Expansion Module


With the rapid development of industrial automation, KEYENCE, as a leading supplier of sensors and measuring instruments, is constantly developing and manufacturing newer and more reliable products to meet the demands of various manufacturing industries. In addition to high-quality products, the well-trained KEYENCE sales team also offers excellent services, ranging from solving application problems, providing technical sales support to responding quickly to users' requests. KEYENCE has always been committed to supporting a wide range of users and helping them become leaders in their industries. Company Information n nCompany Name: KEYENCE n nDate of Establishment: May 27, 1974 n nRegistered Capital: 2,451 million RMB (30,638 million Japanese yen) n nHead Office and Research Center: 1-3-14, Nakajima, Higashiyodo, Osaka n nNumber of Employees: 3,150 (March 2011) n nBusiness Content: Sensors, Measuring instruments, Image Systems, Control? Research on measuring instruments? Analytical instruments for development

KEYENCE KV-B16XC 16-Point DC Input Expansion Module




Achievers Automation Limited has more than 14 years experience in the market of Industrial Automation, specialized in reselling factory sealed Probe, Sensor, DCS,isolator barrier, HMI, PLC,Adapter,Profibus connector and cable from Brands .

KEYENCE KV-B16XC 16-Point DC Input Expansion Module

Below are the TOP BRANDS we handle in the past 14 years:

KEYENCE KV-B16XC 16-Point DC Input Expansion Module


FAQ of Achievers

Q:Are the Products Genuine OEM Units?

A: These items have been certified by Achievers Automation Limited to be genuine OEM Units obtained through OEM or independent third-party channels.

Q:How will you arrange shipment?

A: We can arrange shipment based on your request. We have cooperated forwader who can arrange shipment via FedEx, DHL,TNT with good price.

Q:What is the warranty of goods?

A: One-year Warranty.
