Keyence LK-H082 Spot‑Type Laser Displacement Sensor Head
Keyence LK-H082 Spot‑Type Laser Displacement Sensor Head
Keyence LK-H082 Spot‑Type Laser Displacement Sensor Head
Keyence LK-H082 Spot‑Type Laser Displacement Sensor Head
Specifications
Model Number :
LK-H082
Supply Ability :
100PC
Head Mount :
DIN form B head mount
Special Features :
Integrated TwinCAT 3 runtime environment
Packaging Details :
carton
Operating Temperature :
-25°C to +60°C
Brand Name :
KEYENCE
Indicator :
Power indicator
Price :
negotiate
Measuring Range :
150 mm
Product No :
BSW000R
Payment Terms :
T/T,Alipay,Paypal,XT
Temperature Range :
-25°C To +60°C
Place of Origin :
China
MOQ :
1
Line Voltage :
200 to 600 Volts AC
Description

Keyence LK-H082 Spot‑Type Laser Displacement Sensor Head


Manufacturer :KEYENCE
Product No. : LK-H082

Parameter Item LK‑H082 Detailed Data
Sensor Model LK‑H082
Detection Mode Diffuse‑reflection / Specular‑reflection
Standard Reference Distance 80 mm (diffuse‑reflection); 76.7 mm (specular‑reflection)
Full Measurement Range ±18 mm (diffuse‑reflection); −17.6 mm ~ +14.5 mm (specular‑reflection)
Light Source Red semiconductor laser, 655 nm wavelength
Laser Safety Class IEC 60825‑1 Class 2, FDA CDRH Class II, max 0.95 mW output
Laser Spot Diameter Ø70 μm under standard working distance
Repeatability Accuracy 0.1 μm
Linearity Tolerance ±0.02 % of full‑scale (36 mm)
Selectable Sampling Cycle 2.55 / 5 /10 /20 /50 /100 /200 /500 /1000 μs (9‑speed switchable)
Temperature Drift Coefficient 0.01 % FS per ℃


Performance Parameter Specification
Enclosure Protection Grade IP67 waterproof and dust‑proof
Sensor Housing Material Cast aluminium alloy
Net Weight Approx. 280 g
Operating Ambient Temperature 0 ℃ ~ +50 ℃
Working Humidity 35 %‑85 % RH, non‑condensing
Anti‑Vibration Standard 10–55 Hz, 1.5‑mm peak‑to‑peak amplitude, 2‑hour test on X/Y/Z axes
Max Ambient Light Resistance 10000 lux for incandescent and fluorescent lighting


Keyence LK-H082 Spot‑Type Laser Displacement Sensor Head

Brand


Keyence LK-H082 Spot‑Type Laser Displacement Sensor Head


With the rapid development of industrial automation, KEYENCE, as a leading supplier of sensors and measuring instruments, is constantly developing and manufacturing newer and more reliable products to meet the demands of various manufacturing industries. In addition to high-quality products, the well-trained KEYENCE sales team also offers excellent services, ranging from solving application problems, providing technical sales support to responding quickly to users' requests. KEYENCE has always been committed to supporting a wide range of users and helping them become leaders in their industries. Company Information n nCompany Name: KEYENCE n nDate of Establishment: May 27, 1974 n nRegistered Capital: 2,451 million RMB (30,638 million Japanese yen) n nHead Office and Research Center: 1-3-14, Nakajima, Higashiyodo, Osaka n nNumber of Employees: 3,150 (March 2011) n nBusiness Content: Sensors, Measuring instruments, Image Systems, Control? Research on measuring instruments? Analytical instruments for development

Keyence LK-H082 Spot‑Type Laser Displacement Sensor Head




Achievers Automation Limited has more than 14 years experience in the market of Industrial Automation, specialized in reselling factory sealed Probe, Sensor, DCS,isolator barrier, HMI, PLC,Adapter,Profibus connector and cable from Brands .

Keyence LK-H082 Spot‑Type Laser Displacement Sensor Head

Below are the TOP BRANDS we handle in the past 14 years:

Keyence LK-H082 Spot‑Type Laser Displacement Sensor Head


FAQ of Achievers

Q:Are the Products Genuine OEM Units?

A: These items have been certified by Achievers Automation Limited to be genuine OEM Units obtained through OEM or independent third-party channels.

Q:How will you arrange shipment?

A: We can arrange shipment based on your request. We have cooperated forwader who can arrange shipment via FedEx, DHL,TNT with good price.

Q:What is the warranty of goods?

A: One-year Warranty.
