Specifications
Model Number :
FS-N41P
Supply Ability :
100PC
Head Mount :
DIN form B head mount
Special Features :
Integrated TwinCAT 3 runtime environment
Packaging Details :
carton
Operating Temperature :
-25°C to +60°C
Brand Name :
KEYENCE
Indicator :
Power indicator
Price :
negotiate
Measuring Range :
150 mm
Product No :
BSW000R
Payment Terms :
T/T,Alipay,Paypal,XT
Temperature Range :
-25°C To +60°C
Place of Origin :
China
MOQ :
1
Line Voltage :
200 to 600 Volts AC
Description

Keyence FS-N41P Digital Fiber Optic Sensor Amplifier


Manufacturer :KEYENCE
Product No. : FS-N41P

Parameter Specification
Model Number FS-N41P
Brand Keyence
Series FS-N Digital Fiber Optic Amplifier Series
Unit Type Cable Type, Main Unit
Output Type PNP Open Collector
Number of Control Output 1 channel
Light Source Red four-element LED, 660 nm
Response Speed Modes 23 µs (S-HSPD) / 50 µs (HSPD) / 250 µs (FINE) / 500 µs (TURBO) / 1 ms (SUPER) / 4 ms (ULTRA) / 16 ms (MEGA) / 64 ms (TERA)
Supply Voltage 10 VDC ~ 30 VDC (ripple ≤10% P-P)
Max Output Load Current ≤100 mA
Residual Output Voltage ≤2.2 V (10–100 mA)
Power Consumption Normal: ≤910 mW; ECO ON: ≤840 mW; ECO FULL: ≤750 mW
Anti-interference Capacity Up to 8 units side-by-side (TURBO mode)
Protection Functions Reverse polarity, overcurrent, surge protection


Parameter Specification
Housing Material Polycarbonate
Mounting Method Standard DIN rail mounting
Ambient Operating Temperature -20 °C ~ +55 °C (non-freezing)
Storage Temperature -25 °C ~ +70 °C
Allowable Ambient Light Incandescent lamp ≤20,000 lux, Sunlight ≤30,000 lux
Vibration Resistance 10–55 Hz, 1.5 mm double amplitude, 2 hours on X/Y/Z axis
Shock Resistance 500 m/s², 3 shocks for each X/Y/Z axis
Cable Specification Integrated 2 m cable
Protection Class IP40 (amplifier body)
Approvals UL, CSA, CE
Compliance RoHS



Keyence FS-N41P  Digital Fiber Optic Sensor Amplifier

Brand


Keyence FS-N41P  Digital Fiber Optic Sensor Amplifier


With the rapid development of industrial automation, KEYENCE, as a leading supplier of sensors and measuring instruments, is constantly developing and manufacturing newer and more reliable products to meet the demands of various manufacturing industries. In addition to high-quality products, the well-trained KEYENCE sales team also offers excellent services, ranging from solving application problems, providing technical sales support to responding quickly to users' requests. KEYENCE has always been committed to supporting a wide range of users and helping them become leaders in their industries. Company Information n nCompany Name: KEYENCE n nDate of Establishment: May 27, 1974 n nRegistered Capital: 2,451 million RMB (30,638 million Japanese yen) n nHead Office and Research Center: 1-3-14, Nakajima, Higashiyodo, Osaka n nNumber of Employees: 3,150 (March 2011) n nBusiness Content: Sensors, Measuring instruments, Image Systems, Control? Research on measuring instruments? Analytical instruments for development

Keyence FS-N41P  Digital Fiber Optic Sensor Amplifier




Achievers Automation Limited has more than 14 years experience in the market of Industrial Automation, specialized in reselling factory sealed Probe, Sensor, DCS,isolator barrier, HMI, PLC,Adapter,Profibus connector and cable from Brands .

Keyence FS-N41P  Digital Fiber Optic Sensor Amplifier

Below are the TOP BRANDS we handle in the past 14 years:

Keyence FS-N41P  Digital Fiber Optic Sensor Amplifier


FAQ of Achievers

Q:Are the Products Genuine OEM Units?

A: These items have been certified by Achievers Automation Limited to be genuine OEM Units obtained through OEM or independent third-party channels.

Q:How will you arrange shipment?

A: We can arrange shipment based on your request. We have cooperated forwader who can arrange shipment via FedEx, DHL,TNT with good price.

Q:What is the warranty of goods?

A: One-year Warranty.
