Specifications
Brand Name :
BaseTi
Model Number :
THJB003
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
1
Price :
CONTACT US
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10,000 tons/month
Delivery Time :
15 DAYS
Packaging Details :
External: wooden box packaging; Inside: an inner packing with protective foam;
Production standards :
ASTM F136, ASTM F67, ISO 5832
Tolerance :
+/-0.1mm, Width +/-1mm, Length +/-2mm
Grade :
Ti-6Al-4V, Ti-6Al-7Nb, Ti-3Al-2.5V, Grade 2, Grade 5
Rolling process :
Hot rolling, cold rolling
Surface process :
Polished, anodized, sandblasted
Size :
Thickness 0.5-60mm, Width 200-3000mm, Length 500-12000mm
Description

Titanium Alloy Sheet Plate For Aerospace Healthcare Medical Devices Oil & Gas Industry Automotive

Titanium Alloy Sheet - Overview

*If you have any requirements for customized titanium alloy sheet, we would be delighted to further discuss the technical specifications with you and provide a quotation.

*Our production capacity is efficient, and our logistics channels are well-developed. We can deliver products via international express to any corner of the globe within 3 to 7 days.

Titanium alloy sheet specifications & parameters
Product name Titanium alloy sheet
Application field Aerospace, medical implants, automotive, marine applications
Available size 0.5-60mm, Width 200-3000mm, Length 500-12000mm or Customizable.
Grade Ti-6Al-4V, Ti-6Al-7Nb, Ti-3Al-2.5V, Grade 2, Grade 5
Production stadards ASTM B265, ASTM F136, ISO 5832
Tolerance Thickness +/-0.1mm, Width +/-1mm, Length +/-2mm
Rolling process Hot rolling, cold rolling
Surface process Polished, anodized, sandblasted
Delivery time 12-15days
Key words
  • Titanium Alloy Sheets
  • Aerospace Industry
  • Healthcare
  • Oil & Gas
  • Automotive
  • Titanium factory
  • Titanium manufacturer

Titanium Alloy Sheet - Applications

Introduction

Titanium alloy sheets stand out as a material of choice in various applications due to their unique combination of strength, corrosion resistance, and low weight. From aerospace to healthcare, BaseTi, a leading titanium manufacturer, continues to pave the way for advancements in these sectors.

  • Aerospace Industry

The aerospace sector's demand for titanium alloy sheets has been skyrocketing. According to the Aerospace Industries Association, the use of titanium in aircraft manufacturing has increased by 8% in the past year alone.

Solution: Titanium alloy sheets offer incredible strength and are lightweight, making them ideal for aircraft structures. In addition, they are highly resistant to the corrosive environment at high altitudes.

  • Healthcare and Medical Devices

Statistics from the American Hospital Association indicate that approximately 6.1 million surgeries involving implants are performed annually in the United States.

Solution: In medical implants and devices, titanium alloy sheets are crucial for their biocompatibility and lightweight nature, which provides patients with more comfort and quicker recovery.

  • Oil & Gas Industry

Titanium’s use in oil and gas has increased by 5% over the last three years, according to industry reports.

Solution: In corrosive environments like oil rigs, titanium alloy sheets offer unparalleled corrosion resistance, thereby extending the lifecycle of equipment.

  • Automotive Industry

With fuel-efficiency requirements becoming more stringent, the automotive industry is increasingly looking at lightweight materials.

Solution: The high strength-to-weight ratio of titanium alloy sheets makes them an ideal candidate for critical components, reducing the overall weight of vehicles.

BaseTi - The Titanium Factory You Can Trust

As a leading titanium manufacturer, BaseTi offers a wide range of titanium alloy sheets that meet international standards. We continuously invest in R&D to provide solutions that are not just efficient but also cost-effective.

Aerospace Titanium Alloy Plate Sheet For Healthcare Medical Devices 200 - 3000mm

Common Specifications for Titanium Alloy Sheet
U.S. Grade European Grade Standard Chemical Composition
Application Area
Specific Product
Ti 6Al-4V Ti64 ASTM B265 90% Ti, 6% Al, 4% V Aerospace, Medical Devices Aircraft components, Implants
Grade 2 Ti40A ASTM B265 >99% Ti, O 0.25% Marine, Chemical Processing Hulls, Heat Exchangers
Grade 5 Ti-6Al-4V ASTM F136 90% Ti, 6% Al, 4% V Aerospace, Automotive Jet engines, Car exhaust systems
Grade 12 Ti-0.3Mo-0.8Ni ASTM B265 >99% Ti, 0.3% Mo, 0.8% Ni Chemical, Marine Tanks, Valves
Ti 5Al-2.5Sn NA ASTM B265 90% Ti, 5% Al, 2.5% Sn Aerospace, Energy Airframe structures, Reactors

Chemical Composition for Titanium Alloy Sheet
U.S. Grade European Grade
Chemical Composition (wt%)
Ti 6Al-4V Ti64 Ti90, Al6, V~4, Fe<0.25, O<0.2, N<0.05, C<0.08, H<0.015
Grade 2 Ti40A Ti~99.2, Fe<0.3, O<0.25, N<0.03, C<0.08, H<0.015
Grade 5 Ti-6Al-4V Ti90, Al6, V~4, Fe<0.4, O<0.2, N<0.05, C<0.1, H<0.015
Grade 12 Ti-0.3Mo-0.8Ni Ti98.9, Mo0.3, Ni~0.8, Fe<0.3, O<0.25, N<0.03, C<0.08, H<0.015
Ti 5Al-2.5Sn NA Ti92.5, Al5, Sn~2.5, Fe<0.25, O<0.2, N<0.05, C<0.1, H<0.015

TITANIUM ALLOY SHEET PHYSICAL PROPERTIES
U.S. Grade
European Grade
Density (g/cm³) Melting Point (°C) Thermal Conductivity (W/m·K) Specific Heat Capacity (J/g·K)
Ti 6Al-4V Ti64 4.43 1,660 6.7 0.52
Grade 2 Ti40A 4.51 1,675 21.9 0.56
Grade 5 Ti-6Al-4V 4.43 1,650 7.2 0.54
Grade 12 Ti-0.3Mo-0.8Ni 4.48 1,630 17.5 0.58
Ti 5Al-2.5Sn N/A 4.50 1,645 15.0 0.57

Most of our collaborations are with mechanical workshops and manufacturers, and this gives us practical insights into what exactly you need. Our experience translates into a smoother, more efficient working relationship with you.

Experience the next level of dental innovation with BaseTi's titanium disk & disc solutions.

Contact us to discover how we're transforming the landscape of dental excellence.
