Gr1 Gr2 Gr5 Thin Aerospace Titanium Plate ASTM B265 ASME SB265 Hot Rolled Cold Rolled
Gr1 Gr2 Gr5 Thin Aerospace Titanium Plate ASTM B265 ASME SB265 Hot Rolled Cold Rolled
Gr1 Gr2 Gr5 Thin Aerospace Titanium Plate ASTM B265 ASME SB265 Hot Rolled Cold Rolled
Gr1 Gr2 Gr5 Thin Aerospace Titanium Plate ASTM B265 ASME SB265 Hot Rolled Cold Rolled
Specifications
Brand Name :
BaseTi
Model Number :
THJB007
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
NO MOQ LIMITATION.
Price :
CONTACT US
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10,000 tons/month
Delivery Time :
15 DAYS
Packaging Details :
External: wooden box packaging; Inside: an inner packing with protective foam;
Hardness :
Generally in the range of 32-38 HRC
Heat Treatment :
Annealing at 700-785°C
Production standards :
ASTM B265, ASME SB265, ISO 9001
Grade :
Gr1, Gr2, Gr5, Gr7
Tolerance :
Thickness: ±0.05mm; Width: ±0.5mm; Length: ±1.0mm
Rolling process :
Hot Rolled, Cold Rolled
Surface process :
Acid Wash, Sand Blasting, Polished
Description

Gr1, Gr2, Gr5, Gr7 Titanium Alloy Sheet Plate ASTM B265, ASME SB265, ISO 9001 Hot Rolled, Cold Rolled

Titanium Alloy Sheet - Overview

*If you have any requirements for customized titanium alloy sheet, we would be delighted to further discuss the technical specifications with you and provide a quotation.

*Our production capacity is efficient, and our logistics channels are well-developed. We can deliver products via international express to any corner of the globe within 3 to 7 days.

Titanium alloy sheet specifications & parameters
Product name
Titanium alloy sheet
Application field
Aerospace, Automotive, Chemical Processing, Medical Devices
Available size
Thickness: 0.5-150mm; Width: 1000-2500mm; Length: 2000-6000mm
Grade
Gr1, Gr2, Gr5, Gr7
Production stadards
ASTM B265, ASME SB265, ISO 9001
Tolerance
Thickness: ±0.05mm; Width: ±0.5mm; Length: ±1.0m
Rolling process
Hot Rolled, Cold Rolled
Surface process
Acid Wash, Sand Blasting, Polished
Delivery time
12-15days
Key words
titanium factory, titanium manufacturer, titanium sheet for industrial, ASTM B265, ISO 9001, aerospace, automotive, chemical processing, energy sector, medical industry.

Titanium Alloy Sheet - Applications

Introduction

Industrial sectors worldwide are in constant pursuit of materials that offer high performance, longevity, and cost-efficiency. Titanium sheet for industrial applications stands out as a transformative solution. As a leading titanium factory and manufacturer, BaseTi consistently delivers top-quality titanium sheet products that are driving innovation across industries.

  • Aerospace Industry

The aerospace sector is subject to extreme conditions that require materials with exceptional strength and lightness. Titanium sheets offer just that. Data from the sector reveals that using titanium sheet can result in fuel savings of up to 40% over the life of an aircraft.

  • Automotive Sector

The increasing emphasis on lightweight and fuel-efficient vehicles puts titanium sheets at the forefront. Reports suggest that the incorporation of titanium sheets can enhance vehicle lifespan by 20% while reducing maintenance costs.

  • Chemical Processing

Chemical plants are harsh environments where corrosion resistance is crucial. Titanium sheet for industrial use boasts superior corrosion resistance, resulting in a 25% increase in equipment lifespan.

  • Energy Sector

In power plants and energy systems, titanium sheets are replacing traditional materials due to their high thermal stability and resistance to erosion. Studies indicate that they can withstand temperatures up to 600°C without compromising structural integrity.

  • Medical Industry

The biocompatibility of titanium makes it a prime candidate for medical implants and surgical instruments. In terms of durability and biocompatibility, titanium sheets have an impressive 98% success rate.

  • Why Choose BaseTi?

BaseTi is a renowned titanium factory and titanium manufacturer, rigorously adhering to international production standards like ASTM B265 and ISO 9001. Our titanium sheets offer unparalleled reliability and performance, tailored to meet your industrial needs.

Conclusion

From aerospace to medical technology, BaseTi's titanium sheets are redefining the capabilities and possibilities in industrial applications. Our reputation as a trustworthy titanium manufacturer is backed by years of experience and countless satisfied customers.

Gr1 Gr2 Gr5 Thin Aerospace Titanium Plate ASTM B265 ASME SB265 Hot Rolled Cold Rolled

Chemical Composition for Titanium Alloy Sheet

Grade

Standard

(Ti)

(C)

(O)

(N)

(Fe)

(Al)

(V)

(Pd)

Gr1

ASTM B265

Bal.

≤ 0.08

≤ 0.18

≤ 0.03

≤ 0.20

--

--

--

Gr2

ASTM B265

Bal.

≤ 0.08

≤ 0.25

≤ 0.03

≤ 0.30

--

--

--

Gr5

ASTM B265

Bal.

≤ 0.08

≤ 0.20

≤ 0.05

≤ 0.40

5.5-6.75

3.5-4.5

--

Gr7

ASTM B265

Bal.

≤ 0.08

≤ 0.25

≤ 0.03

≤ 0.30

--

--

0.12-0.25

Physical Properties of Titanium Alloy Sheet
Grade Standard Tensile Strength (MPa)
Yield Strength (MPa)
 Elongation (%) Hardness (HV) Common Applications
Gr1 ASTM B265 240-370 170-310 24-30 120-150 Chemical Processing
Gr2 ASTM B265 340-410 275-355 20-30 150-200 Aerospace, Medical
Gr5 ASTM B265, AMS 4911 950-1000 880-920 15-20 300-350 Aerospace, Automotive
Gr7 ASTM B265 340-410 275-355 20-30 150-200 Chemical Processing

Expert's View: The data clearly show that different grades of titanium sheets serve different needs. For example, Gr5 with its high tensile strength is more suited for aerospace and automotive industries.

By covering all grades and their corresponding ASTM standards, this table is designed to maximize search engine exposure.

Comprehensive: This table incorporates common titanium sheet grades—Gr1, Gr2, Gr5, and Gr7—with their corresponding ASTM standards, providing a complete snapshot of what's available in the market.
