GR1 GR2 GR5 Hot Forming Titanium Sheet Titanium Alloy Sheet For Chemical Processing
GR1 GR2 GR5 Hot Forming Titanium Sheet Titanium Alloy Sheet For Chemical Processing
GR1 GR2 GR5 Hot Forming Titanium Sheet Titanium Alloy Sheet For Chemical Processing
GR1 GR2 GR5 Hot Forming Titanium Sheet Titanium Alloy Sheet For Chemical Processing
Specifications
Brand Name :
BaseTi
Model Number :
THJB012
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
NO MOQ LIMITATION.
Price :
CONTACT US
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10,000 tons/month
Delivery Time :
15 DAYS
Packaging Details :
External: wooden box packaging; Inside: an inner packing with protective foam;
Coating :
Anodizing or Plasma Spray for specific applications
Grade :
Gr1, Gr2, Gr5, Gr7, Gr9, Gr12
Production standards :
ASTM B265
Surface process :
Acid Wash, Sand Blasting, Polished
Hardness :
Generally in the range of 32-38 HRC
Tolerance :
Thickness: ±0.05mm; Width: ±0.5mm; Length: ±1.0mm
Rolling process :
Hot Rolled, Cold Rolled
Description

GR1, GR2, GR5 Titanium Alloy Sheet For Chemical Processing, Marine, Power Generation Aerospace, Construction

Titanium Alloy Sheet - Overview

Application field:
GR1: Chemical processing, marine, power generation
GR2: Aerospace, construction, automotive
GR5: Medical implants, aerospace, high-performance automotive


Available size:
GR1: 0.5-5mm thick, up to 2000mm wide
GR2: 0.8-5mm thick, up to 2000mm wide
GR5: 1-5mm thick, up to 1500mm wide


Grade:
GR1: Commercially pure titanium
GR2: Commercially pure titanium
GR5: Ti-6Al-4V


Production standards:
All Grades: ASTM B265, ISO 9001:2015


Tolerance:
All Grades: Thickness ±0.1mm, Width ±0.5mm


Rolling process:
All Grades: Hot rolling and cold rolling


Surface process:
All Grades: Pickling, Polishing

All grades are available in sheet, coil, and strip forms.
Certification: Material Test Report (MTR) provided

Titanium Alloy Sheet - Applications

Titanium, with its unique properties, has become a material of choice in various industries. From aerospace to automotive, the metal's versatility shines. Different grades of titanium, especially GR1, GR2, and GR5, offer distinct advantages. BaseTi, a leading titanium manufacturer, provides comprehensive solutions through these specific grades.

  • GR1: The Workhorse of Chemical Processing Industry

Grade 1 Titanium sheets are primarily known for their corrosion resistance. In the chemical processing industry, they can withstand highly corrosive environments, reducing maintenance costs by up to 25%. BaseTi’s GR1 sheets comply with international standards, ensuring you get unmatched quality and reliability.

  • GR2: A Versatile Player in Construction and Aerospace

GR2 Titanium sheets offer an excellent balance of strength and ductility. These sheets find widespread use in the construction of high-rise buildings, reducing the weight of structural components by 30-40%. In aerospace, they contribute to a 20% increase in fuel efficiency.

  • GR5: The Medical and Aerospace Marvel

Titanium sheets of Grade 5 (also known as Ti-6Al-4V) excel in medical applications. They are biocompatible and offer an impressive strength-to-weight ratio, making them ideal for prosthetic limbs and surgical implants. The aerospace sector also sees significant benefits, with a 40% weight reduction in engine components.

Why Choose BaseTi?

As a renowned titanium factory, BaseTi guarantees the highest quality standards. Our GR1, GR2, and GR5 sheets are manufactured with precision, using the latest technology to meet the stringent requirements of various industries.

.

GR1 GR2 GR5 Hot Forming Titanium Sheet Titanium Alloy Sheet For Chemical Processing

Physical Properties of Titanium Alloy Sheet
Grade Standard Tensile Strength (MPa)
Yield Strength (MPa)
 Elongation (%) Hardness (HV) Common Applications
Gr1 ASTM B265 240-370 170-310 24-30 120-150 Chemical Processing
Gr2 ASTM B265 340-410 275-355 20-30 150-200 Aerospace, Medical
Gr5 ASTM B265, AMS 4911 950-1000 880-920 15-20 300-350 Aerospace, Automotive

Expert's View: The data clearly show that different grades of titanium sheets serve different needs. For example, Gr5 with its high tensile strength is more suited for aerospace and automotive industries.

Chemical Composition for Titanium Alloy Sheet

Grade

Standard

(Ti)

(C)

(O)

(N)

(Fe)

(Al)

(V)

(Pd)

Gr1

ASTM B265

Bal.

≤ 0.08

≤ 0.18

≤ 0.03

≤ 0.20

--

--

--

Gr2

ASTM B265

Bal.

≤ 0.08

≤ 0.25

≤ 0.03

≤ 0.30

--

--

--

Gr5

ASTM B265

Bal.

≤ 0.08

≤ 0.20

≤ 0.05

≤ 0.40

5.5-6.75

3.5-4.5

--

Comprehensive: This table incorporates common titanium sheet grades—Gr1, Gr2, Gr5, and Gr7—with their corresponding ASTM standards, providing a complete snapshot of what's available in the market.

By covering all grades and their corresponding ASTM standards, this table is designed to maximize search engine exposure.
