ASTM B265 Titanium Alloy Sheet Plate Engineering Gr5 Gr7 Gr9 For Automotive Marine
ASTM B265 Titanium Alloy Sheet Plate Engineering Gr5 Gr7 Gr9 For Automotive Marine
ASTM B265 Titanium Alloy Sheet Plate Engineering Gr5 Gr7 Gr9 For Automotive Marine
ASTM B265 Titanium Alloy Sheet Plate Engineering Gr5 Gr7 Gr9 For Automotive Marine
ASTM B265 Titanium Alloy Sheet Plate Engineering Gr5 Gr7 Gr9 For Automotive Marine
ASTM B265 Titanium Alloy Sheet Plate Engineering Gr5 Gr7 Gr9 For Automotive Marine
Specifications
Brand Name :
BaseTi
Model Number :
THJB012
Certification :
ISO9001:2015
Place of Origin :
China
MOQ :
NO MOQ LIMITATION.
Price :
CONTACT US
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10,000 tons/month
Delivery Time :
15 DAYS
Packaging Details :
External: wooden box packaging; Inside: an inner packing with protective foam;
Coating :
Anodizing or Plasma Spray for specific applications
Grade :
Gr1, Gr2, Gr5, Gr7, Gr9, Gr12
Production standards :
ASTM B265
Surface process :
Acid Wash, Sand Blasting, Polished
Hardness :
Generally in the range of 32-38 HRC
Tolerance :
Thickness: ±0.05mm; Width: ±0.5mm; Length: ±1.0mm
Rolling process :
Hot Rolled, Cold Rolled
Description

ASTM B265 Titanium Alloy Sheet Plate For Aerospace, Medical, Automotive, Marine Engineering Gr1, Gr2, Gr5, Gr7, Gr9

Titanium Alloy Sheet - Overview

*If you have any requirements for customized titanium alloy sheet, we would be delighted to further discuss the technical specifications with you and provide a quotation.

*Our production capacity is efficient, and our logistics channels are well-developed. We can deliver products via international express to any corner of the globe within 3 to 7 days.

ASTM B265 Titanium alloy sheet - Parameters

Product name

Titanium alloy sheet

Application field

Aerospace, Medical, Automotive, Marine Engineering.

Available size

Thickness (0.02-4 in), Width (36-48 in), Length (96-240 in)

Grade

Gr1, Gr2, Gr5, Gr7, Gr9, Gr12

Production stadards

ASTM F67, ASTM F136, ISO 5832.

Tolerance

Thickness (+/-0.1mm), Width (+/-0.5mm), Length (+/-1.0mm)

Rolling process

Hot Rolled, Cold Rolled

Surface process

Acid washing, Sandblasted, Polished

Delivery time

12-15days

Key words

  • Titanium Factory
  • Titanium Manufacturer
  • ASTM B265
  • Aerospace Applications
  • Medical Applications
  • BaseTi
  • High Strength-to-Weight Ratio
  • Corrosion Resistance

Titanium Alloy Sheet - Applications

In the demanding world of material science, titanium sheets manufactured under the ASTM B265 standard offer game-changing solutions across a multitude of industries. Here’s why BaseTi, a leading titanium manufacturer, stands as an exemplar in the domain.

  • Aerospace

The aerospace industry demands materials that are both lightweight and strong. According to industry data, a 1% reduction in aircraft weight can lead to a fuel efficiency improvement of up to 0.75%. ASTM B265 titanium sheets fulfill these requirements, offering high strength-to-weight ratios and exceptional corrosion resistance.

  • Medical Field

In medical applications, the biocompatibility of titanium has made ASTM B265 the gold standard. Hip replacements and dental implants made from these sheets have shown lower rejection rates.

  • Marine Engineering

The high tensile strength and corrosion resistance make these titanium sheets from BaseTi ideal for marine applications, effectively reducing maintenance costs by up to 25% compared to other materials.

  • Automotive

Data shows that ASTM B265 titanium sheets have improved the fuel efficiency of cars by 10% due to their lightweight properties when incorporated into exhaust systems.

Manufacturing Standards and Quality
At BaseTi, we adhere strictly to ASTM B265 production standards to ensure high-quality titanium sheets. Our titanium factory employs state-of-the-art technology for precision rolling and surface treatments.

.

ASTM B265 Titanium Alloy Sheet Plate Engineering Gr5 Gr7 Gr9 For Automotive Marine

Physical Properties of Titanium Alloy Sheet
Grade Standard Tensile Strength (MPa)
Yield Strength (MPa)
 Elongation (%) Hardness (HV) Common Applications
Gr1 ASTM B265 240-370 170-310 24-30 120-150 Chemical Processing
Gr2 ASTM B265 340-410 275-355 20-30 150-200 Aerospace, Medical
Gr5 ASTM B265, AMS 4911 950-1000 880-920 15-20 300-350 Aerospace, Automotive
Gr7 ASTM B265 340-410 275-355 20-30 150-200 Chemical Processing

Expert's View: The data clearly show that different grades of titanium sheets serve different needs. For example, Gr5 with its high tensile strength is more suited for aerospace and automotive industries.

Chemical Composition for Titanium Alloy Sheet

Grade

Standard

(Ti)

(C)

(O)

(N)

(Fe)

(Al)

(V)

(Pd)

Gr1

ASTM B265

Bal.

≤ 0.08

≤ 0.18

≤ 0.03

≤ 0.20

--

--

--

Gr2

ASTM B265

Bal.

≤ 0.08

≤ 0.25

≤ 0.03

≤ 0.30

--

--

--

Gr5

ASTM B265

Bal.

≤ 0.08

≤ 0.20

≤ 0.05

≤ 0.40

5.5-6.75

3.5-4.5

--

Gr7

ASTM B265

Bal.

≤ 0.08

≤ 0.25

≤ 0.03

≤ 0.30

--

--

0.12-0.25

Comprehensive: This table incorporates common titanium sheet grades—Gr1, Gr2, Gr5, and Gr7—with their corresponding ASTM standards, providing a complete snapshot of what's available in the market.

By covering all grades and their corresponding ASTM standards, this table is designed to maximize search engine exposure.
