Building Material Titanium Alloy Sheet Plate Ti6Al4V Grade 2 Grade 5 ASTM B265
Building Material Titanium Alloy Sheet Plate Ti6Al4V Grade 2 Grade 5 ASTM B265
Building Material Titanium Alloy Sheet Plate Ti6Al4V Grade 2 Grade 5 ASTM B265
Building Material Titanium Alloy Sheet Plate Ti6Al4V Grade 2 Grade 5 ASTM B265
Building Material Titanium Alloy Sheet Plate Ti6Al4V Grade 2 Grade 5 ASTM B265
Building Material Titanium Alloy Sheet Plate Ti6Al4V Grade 2 Grade 5 ASTM B265
Specifications
Brand Name :
BaseTi
Model Number :
THJB004
Certification :
Material Test Report Available
Place of Origin :
China
MOQ :
1
Price :
CONTACT US
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10,000 tons/month
Delivery Time :
15 DAYS
Packaging Details :
External: wooden box packaging; Inside: an inner packing with protective foam;
Grade :
Ti6Al4V, Grade 2, Grade 5
Production standards :
ASTM B265, ISO 9001
Tolerance :
Thickness +/-0.05 mm, Width +/-0.5 mm, Length +/-1 mm
Rolling process :
Hot rolling, cold rolling
Surface process :
Polished, anodized, sandblasted
Size :
Thickness 0.5-60mm, Width 200-3000mm, Length 500-12000mm
Packaging :
Standard Export Packaging or Custom Packaging
Description

Titanium Alloy Sheet Plate Building Material Ti6Al4V, Grade 2, Grade 5 ASTM B265, ISO 9001

Titanium Alloy Sheet - Overview

*If you have any requirements for customized titanium alloy sheet, we would be delighted to further discuss the technical specifications with you and provide a quotation.

*Our production capacity is efficient, and our logistics channels are well-developed. We can deliver products via international express to any corner of the globe within 3 to 7 days.

Titanium alloy sheet specifications & parameters

Product name

Titanium alloy sheet

Application field

Building and construction, architectural cladding, roofing, structural supports

Available size

Thickness 0.5-20 mm, Width up to 1500 mm, Length up to 6000 mm

Grade

Ti6Al4V, Grade 2, Grade 5

Production stadards

ASTM B265, ISO 9001

Tolerance

Thickness +/-0.05 mm, Width +/-0.5 mm, Length +/-1 mm

Rolling process

Hot-rolled, Cold-rolled

Surface process

Sandblasted, pickled, or polished

Delivery time

12-15days

Key words

Titanium Alloy Sheet, Building Material, Titanium Factory, Titanium Manufacturer, Sustainable Construction, BaseTi, ASTM B265, ISO 9001

Titanium Alloy Sheet - Applications

When it comes to modern construction and building material innovation, Titanium Alloy Sheets stand out as a revolutionary product. With an unmatched blend of strength, corrosion resistance, and durability, these sheets present a sustainable alternative to traditional materials like steel, aluminum, or concrete.

Data-Driven Insights

The global construction industry is projected to reach $10.5 trillion by 2023, with a growing emphasis on sustainable materials. The U.S. alone uses over 40 million tons of metal in construction annually. Titanium Alloy Sheets, as supplied by top-tier titanium manufacturers like BaseTi, are contributing to a more eco-friendly approach.

Why Choose BaseTi Titanium Alloy Sheets for Building Materials?

BaseTi is a leading titanium factory known for its state-of-the-art technology and stringent quality control. Our Titanium Alloy Sheets for building materials meet ASTM B265 and ISO 9001 standards, ensuring you get nothing but the best.

Key Features

  • High Tensile Strength: Over 40% stronger than stainless steel.

  • Corrosion Resistance: Lasts decades longer than other materials in extreme weather conditions.

  • Lightweight: Almost 60% lighter than steel, reducing overall structural load.

Applications in Building Material

  • Architectural Cladding: Provides a modern aesthetic while ensuring long-lasting durability.

  • Roofing: Withstands severe weather, including hail and heavy winds.

  • Structural Supports: Ideal for earthquake-resistant constructions.

Sustainability Factor

Utilizing Titanium Alloy Sheets can lead to a 30% reduction in CO2 emissions, as compared to traditional steel-based structures.

Conclusion

For those in the construction and building materials industry, BaseTi's Titanium Alloy Sheets are not just a choice; they are the future. Our reputation as a reliable titanium manufacturer is backed by years of experience and satisfied customers.

Building Material Titanium Alloy Sheet Plate Ti6Al4V Grade 2 Grade 5 ASTM B265

Common Specifications for Titanium Alloy Sheet
U.S. Grade European Grade Standard Chemical Composition
Application Area
 Specific Product
Ti 6Al-4V Ti64 ASTM B265 90% Ti, 6% Al, 4% V Aerospace, Medical Devices Aircraft components, Implants
Grade 2 Ti40A ASTM B265 >99% Ti, O 0.25% Marine, Chemical Processing Hulls, Heat Exchangers
Grade 5 Ti-6Al-4V ASTM F136 90% Ti, 6% Al, 4% V Aerospace, Automotive Jet engines, Car exhaust systems
Grade 12 Ti-0.3Mo-0.8Ni ASTM B265 >99% Ti, 0.3% Mo, 0.8% Ni Chemical, Marine Tanks, Valves
Ti 5Al-2.5Sn NA ASTM B265 90% Ti, 5% Al, 2.5% Sn Aerospace, Energy Airframe structures, Reactors

Chemical Composition for Titanium Alloy Sheet
U.S. Grade European Grade
Chemical Composition (wt%)
Ti 6Al-4V Ti64 Ti90, Al6, V~4, Fe<0.25, O<0.2, N<0.05, C<0.08, H<0.015
Grade 2 Ti40A Ti~99.2, Fe<0.3, O<0.25, N<0.03, C<0.08, H<0.015
Grade 5 Ti-6Al-4V Ti90, Al6, V~4, Fe<0.4, O<0.2, N<0.05, C<0.1, H<0.015
Grade 12 Ti-0.3Mo-0.8Ni Ti98.9, Mo0.3, Ni~0.8, Fe<0.3, O<0.25, N<0.03, C<0.08, H<0.015
Ti 5Al-2.5Sn NA Ti92.5, Al5, Sn~2.5, Fe<0.25, O<0.2, N<0.05, C<0.1, H<0.015

Physical Properties for Titanium Alloy Sheet
U.S. Grade
European Grade
 Density (g/cm³) Melting Point (°C) Thermal Conductivity (W/m·K) Specific Heat Capacity (J/g·K)
Ti 6Al-4V Ti64 4.43 1,660 6.7 0.52
Grade 2 Ti40A 4.51 1,675 21.9 0.56
Grade 5 Ti-6Al-4V 4.43 1,650 7.2 0.54
Grade 12 Ti-0.3Mo-0.8Ni 4.48 1,630 17.5 0.58
Ti 5Al-2.5Sn N/A 4.50 1,645 15.0 0.57

Most of our collaborations are with mechanical workshops and manufacturers, and this gives us practical insights into what exactly you need. Our experience translates into a smoother, more efficient working relationship with you.

Experience the next level of dental innovation with BaseTi's titanium disk & disc solutions.

Contact us to discover how we're transforming the landscape of dental excellence.
