Semi Automatic UHT Sterilization Machine Coil Type Sterilizer Equipment
Semi Automatic UHT Sterilization Machine Coil Type Sterilizer Equipment
Semi Automatic UHT Sterilization Machine Coil Type Sterilizer Equipment
Semi Automatic UHT Sterilization Machine Coil Type Sterilizer Equipment
Semi Automatic UHT Sterilization Machine Coil Type Sterilizer Equipment
Semi Automatic UHT Sterilization Machine Coil Type Sterilizer Equipment
Specifications
Model Number :
KQ1000 - 10000L
Certification :
ISO
MOQ :
1 Set
Price :
Discussible
Payment Terms :
T/T, Western Union
Supply Ability :
200 Sets per month
Delivery Time :
20 - 30 working days
Packaging Details :
Wooden Box
Name :
stainless steel sterilizer Machine
Condition :
New
Material :
SS304
Voltage :
380V 50HZ 3Phase
Warranty :
1 Year
Weight :
1000KG
Packing :
Semi-automatic Stainless steel UHT Coil Type Sterilizer Equipment 2018
Description

Semi-automatic Stainless steel UHT Coil Type Sterilizer Equipment 2018

Product Description

(1)Applied:
fruit juice pasteurizer adopts Ultra High Temperature processing method to strictly sterilize milk and other dairy liquid, beverage, juice etc., before an aseptic packaging.

Semi Automatic UHT Sterilization Machine Coil Type Sterilizer Equipment

(2)Sterilization temperature: 85℃ -145℃.


(3)Sterilization keeping time: 5 - 45s in order to keep the original nutritional substance, color and flavor of the product.


Controlling way: Semi-automatic and Fully automatic (PLC controlling, tactile screen).
Board Type Sterilization Machine

Fruit juice pasteurizer

UHT-1

UHT-2

UHT-3

UHT-4

UHT-5

Product capacityT/h

1

2

3

4

5

Heat exchanging area m2

16

26

38

46

56

Materal inlet temperature ºC

5

5

5

5

5

Materal inlet temperature ºC

5

5

5

5

5

Sterilizing temperature

137

137

137

137

137

137Warmkeeping timeS

4

4

4

4

4

Ice water temperature ºC

1

1

1

1

1

Ice water cos T/h

3

4

6

8

12

Jiont size mm

φ 25

φ 38

φ 38

φ 51

φ 51

Weight kg

980

1080

1160

1350

1680

Size mm

1500 * 1500
* 2000

1900 * 1800
* 2200

1900 * 1800
* 2200

1900 * 1800
* 2200

2600 * 2200
* 2500

power kw

3

4

5

6

6

FAQ

1. Delivery ?
20 - 30 working days after get your advance payment .
2.Payment :
Western Union,TT , 50% in advance ,the rest before shipment .
3. Price available ?
FOB CIF CNF CFR Shanghai/Ningbo China .
4. Can we visit your factory .

Yes , welcome to visit our factory .We can talk face to face and you can check the quality by yourself .
5. How to know the technical details of the UHT Sterilizer ?

Send your inquiry ,we will give you full details with our quotation .
6.Do you have other type UHT sterilizer ?
Yes , we have picture for your reference.

Our Services

Semi Automatic UHT Sterilization Machine Coil Type Sterilizer Equipment

1. Quotation can be available within 1 hours after we get your reply .


2. We provide lifelong technical service.
If the customer needs, we can provide the engineer overseas technical service.Salary negotiable.
