Flash Pasteurization Equipment , Full Automatic UHT Milk Production Line
Flash Pasteurization Equipment , Full Automatic UHT Milk Production Line
Flash Pasteurization Equipment , Full Automatic UHT Milk Production Line
Flash Pasteurization Equipment , Full Automatic UHT Milk Production Line
Specifications
Model Number :
KQ 1000L ,KQ 2000L
Certification :
ISO CE
MOQ :
1Set
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
25 days after get your advance payment .
Delivery Time :
20 to 30 days after get your advance payment
Packaging Details :
Standard Export Wooden Box
Name :
Milk UHT Flash Sterilizer
Material :
Stainless Steel 316 /316L
Inlet Temperature :
20C -65C
Sterilization Temerpature :
110 to 135C
Holding Time :
5 to 30seconds
Outlet temperature :
20C -65C
Application :
Milk ,Juice , Water ,Tea , Eggs Liquid
Warranty :
One year
Origin :
Shanghai China
Description

Full Automatic UHT Flash Sterilizer For Milk Yogurt Production Line

1. UHT Sterilizer Picture and instruction :


It applies to the sterilization of juice, milk, tea, energy drinks, beer, etc. UHT system includes tubular UHT and Plate UHT.


UHT System Components
- Hot water supplying system
- Plate /tubular heat exchanger
- Product pump
- Product balance tank
- Electrical control cabinet
- Accessory pipes
- Steam pressure reducer and adjusting system
- Temperature adjusting system
- Recorder
- etc.

Technical Description:
Capacity 3-25 T/H
Sterilizing temperature 65-140 C
Sterilizing time 4~30s
Product Juice, milk, tea, energy drinks, beer, etc.
Model
Project		 UHT-1.6 UHT-2 UHT-3 UHT-4 UHT-5
Product capacity(l/h) 1600 2000 3000 4000 5000
Material inlet temperature 5centigrade 5centigrade 5centigrade 5centigrade 5centigrade
Warmkeeping time(s) 4-15 4-15 4-15 4-15 4-15
Sterilizing temperature 95~141centigrade 95~141centigrade 95~141centigrade 95~141centigrade 95~141centigrade
Material outlet temperature 4-20 4-20 4-20 4-20 4-20
Steam pressure 0.6MPa 0.6MPa 0.6MPa 0.6MPa 0.6MPa
Steam cost ~130kg/h ~160kg/h ~240kg/h ~320kg/h ~400kg/h
Compressed air pressure 0.6MPa 0.6MPa 0.6MPa 0.6MPa 0.6MPa
Compressed air cost 50L/H 50L/H 50L/H 50L/H 50L/H
Size
(Without homogenizer)		 3500×1600
×1800		 4500×2000
×1900		 4500×2500
×2000		 5000×2000
×2000		 5000×2000
×2000
Electrisity cost(kw)
(without homogenizer)		 4.5 4.5 5.5 6.5 10

Flash Pasteurization Equipment , Full Automatic UHT Milk Production Line

Working principle
1).Put the product from a storage tank mounted for the sterilizer into the heat exchanger unit.
2).Heat the product by superheated water till the sterilizing temp and hold the product under the temp for sterilizing the product, then cool down into filling temperature by cooling water or chilled water.
3).Before each production shift, sterilize in place the system with aseptic filler together by superheated water.
4).After each production shift, clean in place the system with aseptic filler together by hot water, alkali liquid and acid liquid.
