Field Wireable M8 Connectors 3 Pin A Code Waterproof IP67 Industrial Circular Connector
Field Wireable M8 Connectors 3 Pin A Code Waterproof IP67 Industrial Circular Connector
Field Wireable M8 Connectors 3 Pin A Code Waterproof IP67 Industrial Circular Connector
Field Wireable M8 Connectors 3 Pin A Code Waterproof IP67 Industrial Circular Connector
Specifications
Brand Name :
KRONZ
Model Number :
H0803FA-0
Certification :
CE
Place of Origin :
Guangdong, China
MOQ :
50 pieces
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
100000 pieces per month
Delivery Time :
5-8 working days
Packaging Details :
Polybag packing
Price :
Negotiable
Type :
M8
Product name :
M8 Field Wirable Assembly Connector
Standard :
IEC 61076-2-104
Contact nut material :
Brass, nickle-plated
Contact carrier material :
PA, black
Seal material :
FPM/FKM
Ambient temperature :
-25~+85℃
Endurance(shell) :
>100 cycles
Description

M8 Connector Field-wireable 3 Pin A Code Waterproof IP67 Industrial Circular Connector


Product Description


M8 Female Connector - 3 Pins (A Code) – Versatile Connection Solution

The M8 3-pin female connector with A-code is designed to pair seamlessly with M8 male connectors. It’s commonly used in applications where the connector needs to fit into a female interface. The 3-pin design offers a simplified connection for sensor systems and control units. What is field-wireable connector? It can be assembled and wired by hand on-site, without the need for pre-molded cables.



Field Wireable M8 Connectors 3 Pin A Code Waterproof IP67 Industrial Circular Connector


Technical Data


Standard IEC 61076-2-104
Contact nut material Brass, nickle-plated
Contact surface material Brass, gold-plated
Contact carrier material PA, black
Housing material TPU, black
Seal material FPM/FKM
Insulation resistance ≥100MΩ
Contact resistance ≤5mΩ
Pollution degree 3
Ambient temperature -25~+85℃
Mating cycles >100
Degree of protection IP67


Pin assignment Connection method Coding Rated current Voltage Cable outlet External cable diameter Model No.
Field Wireable M8 Connectors 3 Pin A Code Waterproof IP67 Industrial Circular Connector Screw connection A 3A 60V Angled 3.5-5mm

H0803FA-0


Field Wireable M8 Connectors 3 Pin A Code Waterproof IP67 Industrial Circular Connector

Field Wireable M8 Connectors 3 Pin A Code Waterproof IP67 Industrial Circular Connector

Field Wireable M8 Connectors 3 Pin A Code Waterproof IP67 Industrial Circular Connector

Field Wireable M8 Connectors 3 Pin A Code Waterproof IP67 Industrial Circular Connector

Field Wireable M8 Connectors 3 Pin A Code Waterproof IP67 Industrial Circular Connector

Field Wireable M8 Connectors 3 Pin A Code Waterproof IP67 Industrial Circular Connector
