Specifications
Brand Name :
PR
Model Number :
PR 9203B
Certification :
CO
Place of Origin :
Denmark
MOQ :
1
Price :
160-360usd
Payment Terms :
T/T
Supply Ability :
99pcs 4-6 weeks
Delivery Time :
5-7 work days
Mountingtype :
DIN Rail or Panel Mount
Dimensions :
100mm x 22.5mm x 110mm
Outputcurrent :
Max 100mA
Enclosurematerial :
Aluminum or Stainless Steel
Powerrating :
1W to 5W
Operatingtemperaturerange :
-40°C to +70°C
Outputvoltage :
24V DC
Inputvoltage :
24V DC
Safetyapprovals :
Ex ia IIC, Ex ib IIC
Ingressprotection :
IP20 to IP65
Inputcurrent :
Max 100mA
Isolationvoltage :
2500V AC
Productname :
Intrinsic Safety Barriers
Responsetime :
Less than 1ms
Description
Solenoid / Alarm Driver PR 9203B

Universal Ex driver for solenoids, acoustic alarms and LEDs with extended self-diagnostics. Available in 1 or 2 channel configurations. Can be supplied separately or installed on power rail PR 94.

Environmental Conditions
Operating temperature -20°C to +60°C
Storage temperature -20°C to +85°C
Calibration temperature 20...28°C
Relative humidity < 95% RH (non-condensing)
Protection degree IP20
Installation in Pollution degree 2 & measurement / overvoltage category II
Mechanical Specifications
Dimensions (HxWxD) 109 x 23.5 x 104 mm
Dimensions (HxWxD) with PR 4500 109 x 23.5 x 131 mm
Weight approx. 170 g
DIN rail type DIN EN 60715/35 mm
Wire size 0.13...2.08 mm² AWG 26...14 stranded wire
Screw terminal torque 0.5 Nm
Vibration IEC 60068-2-6
2...13.2 Hz: ±1 mm
13.2...100 Hz: ±0.7 g
Common Specifications
Supply
Supply voltage 19.2...31.2 VDC
Fuse 1.25 A SB / 250 VAC
Max. required power ≤ 1.9 W / ≤ 3.1 W (1 / 2 ch.) - low current
≤ 2.5 W (1 ch.) - high current
Max. power dissipation, 1 / 2 ch. ≤ 1.1 W / ≤ 2.0 W (1 / 2 ch.) - low current
Max. power dissipation ≤ 1.7 W (1 ch.) - high current
Isolation Voltage
Test/working: Input to any 2.6 kVAC / 300 VAC reinforced isolation
Output 1 to output 2 1.5 kVAC / 150 VAC reinforced isolation
Status relay to supply 1.5 kVAC / 150 VAC reinforced isolation
Programming PR 4500 communication interfaces
EMC immunity influence < ±0.5% of span
Extended EMC immunity: NAMUR NE21, A criterion, burst < ±1% of span
Input Specifications
NPN and Mechanical Switch
Trigger level LOW ≤ 2.0 VDC
Trigger level HIGH ≥ 4.0 VDC
Max. external voltage 28 VDC
Input impedance 3.5 kΩ
PNP
Trigger level LOW ≤ 8.0 VDC
Trigger level HIGH ≥ 10.0 VDC
Max. external voltage 28 VDC
Input impedance 3.5 kΩ
Output Specifications
Status Relay
Max. voltage 125 VAC / 110 VDC
Max. current 0.5 AAC / 0.3 ADC
Max. AC power 62.5 VA / 32 W
Output ripple < 40 mVRMS
Compliance & Authority Requirements
EMC 2014/30/EU & UK SI 2016/1091
LVD 2014/35/EU & UK SI 2016/1101
ATEX 2014/34/EU & UK SI 2016/1107
RoHS 2011/65/EU & UK SI 2012/3032
EAC TR-CU 020/2011
EAC Ex TR-CU 012/2011
EAC LVD TR-CU 004/2011
Approvals & Certifications
ATEX KEMA 07ATEX0147 X
IECEx KEM 09.0001X
UKEX DEKRA 21UKEX0181X DEKRA 23UKEX0106X
FM US FM19US0057X / FM19CA0030X
INMETRO DEKRA 23.0008X
UL US, UL 61010-1 E314307
UL US, UL 913 E233311 (only 9203xxxx-U9)
CCC 2020322304003423
KCs 21_AV4BO_0182X / 21_AV4BO_0183X (only 9203Bxxx-KCs)
EAC Ex EAEU KZ 7500361.01.01.08756
DNV Marine TAA00000JD
ClassNK TA24034M
SIL SIL 2 certified & fully assessed according to IEC 61508
