UL 913 Ex-isolated Driver 3 / 5 Port 3.75 KVAC Galvanic Isolation Driver
UL 913 Ex-isolated Driver 3 / 5 Port 3.75 KVAC Galvanic Isolation Driver
UL 913 Ex-isolated Driver 3 / 5 Port 3.75 KVAC Galvanic Isolation Driver
UL 913 Ex-isolated Driver 3 / 5 Port 3.75 KVAC Galvanic Isolation Driver
UL 913 Ex-isolated Driver 3 / 5 Port 3.75 KVAC Galvanic Isolation Driver
UL 913 Ex-isolated Driver 3 / 5 Port 3.75 KVAC Galvanic Isolation Driver
UL 913 Ex-isolated Driver 3 / 5 Port 3.75 KVAC Galvanic Isolation Driver
UL 913 Ex-isolated Driver 3 / 5 Port 3.75 KVAC Galvanic Isolation Driver
Specifications
Brand Name :
PR
Model Number :
PR 5105B-U9
Certification :
CO
Place of Origin :
Denmark
MOQ :
1
Price :
150-250usd
Payment Terms :
T/T
Supply Ability :
99pcs 4-6 weeks
Delivery Time :
5-7 work days
Material :
Stainless Steel, Brass
Powersupply :
24 V DC
Measurementtype :
Gauge, Absolute, Differential
Displaytype :
LCD, LED
Connectiontype :
Threaded, Flanged
Outputsignal :
4-20 mA, 0-10 V, Digital
Application :
Industrial, HVAC, Automotive, Oil & Gas
Pressurerange :
0 to 10,000 psi
Protectionrating :
IP65, IP67
Accuracy :
±0.1% FS
Productname :
Pressure Measurement Instruments
Operatingtemperature :
-40°C to 85°C
Mountingoptions :
Panel, Wall, Pipe
Responsetime :
≤ 1 second
Description
Ex-isolated driver
PR 5105B-U9
UL 913-approved version for US market only • 1- or 2-channel version • 3-/5-port 3.75 kVAC galvanic isolation • Driver for I.S. area • 20 programmable measurement ranges
Environmental Conditions
Operating temperature -20°C to +60°C
Calibration temperature 20...28°C
Relative humidity < 95% RH (non-cond.)
Protection degree IP20
Mechanical Specifications
Dimensions (HxWxD) 109 x 23.5 x 130 mm
Weight approx. 225 g
DIN rail type DIN EN 60715/35 mm
Wire size 0.13...2.08 mm² AWG 26...14 stranded wire
Screw terminal torque 0.5 Nm
Vibration IEC 60068-2-6
2...13.2 Hz: ±1 mm
13.2...100 Hz: ±0.7 g
Electrical Specifications
Power Supply
Supply voltage, universal 21.6...253 VAC, 50...60 Hz or 19.2...300 VDC
Fuse 400 mA SB / 250 VAC
Max. required power ≤ 2 W (2 channels)
Internal power dissipation ≤ 2 W (2 channels)
Isolation & Protection
Isolation voltage, test / working 3.75 kVAC / 250 VAC
PELV/SELV IEC 61140
Performance Characteristics
Response time (0...90%, 100...10%) < 25 ms
Programming DIP switches
Signal / noise ratio Min. 60 dB (0...100 kHz)
Accuracy Better than 0.1% of selected range
EMC immunity influence < ±0.5% of span
Extended EMC immunity: NAMUR NE21, A criterion, burst < ±1% of span
Input Specifications
Current Input
Measurement range 0...23 mA
Min. measurement range (span) 16 mA
Input resistance Nom. 10 Ω + PTC 10 Ω
Voltage Input
Measurement range 0...10 VDC
Min. measurement range (span) 8 VDC
Input resistance > 2 MΩ
Output Specifications
Current Output
Signal range 0...23 mA
Min. signal range 16 mA
Load (@ current output) ≤ 770 Ω
Load stability ≤ 0.01% of span / 100 Ω
Current limit ≤ 28 mA
Voltage Output
Signal range 0...1 VDC / 0...10 VDC
Min. signal range 0.8 VDC / 8 VDC
Load (@ voltage output) ≥ 500 kΩ
"of span" refers to the presently selected range
Compliance & Approvals
EMC 2014/30/EU
LVD 2014/35/EU
c UL us, UL 508 05122003-E233311
c UL us, UL 913 05122003-E233311
DNV Marine TAA0000101
