3 Power 6 Signal Industrial Slip Ring With Excellent Safety / Noise Immunity
3 Power 6 Signal Industrial Slip Ring With Excellent Safety / Noise Immunity
3 Power 6 Signal Industrial Slip Ring With Excellent Safety / Noise Immunity
3 Power 6 Signal Industrial Slip Ring With Excellent Safety / Noise Immunity
Specifications
Brand Name :
Panlink
Model Number :
PSR-C12K-9
Certification :
ISO 9001: 2015, CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Packaging Details :
Carton Box, EPE Foam, Wooden Box(For Large Goods)
Name :
Industrial Slip Ring
Circuit :
3 x Power(10A) + 6 x Signal(2A)
Dielectric Strength :
500VAC@50Hz, 60s
Insulation Strength :
1000MΩ@500VDC
Protection Level :
IP54
Price :
Negotiable
Delivery Time :
4 Weeks
Supply Ability :
40 Million a Year
Description

3 Power and 6 Signal Industrial Capsule Slip Ring with Excellent Safety and Noise Immunity

Features Applications
• Circuits: 3 x Power(10A) + 6 x Signal(2A) • The joint segments of industrial robots
• Dielectric Strength: 500VAC@50Hz, 60s • The rotary tables of automated machining centers
• Insulation Strength: 1000MΩ@500VDC • The rotating units of packaging and textile machinery
• Protection Level: IP54 • The rotating platforms of material handling conveyor lines

3 Power 6 Signal Industrial Slip Ring With Excellent Safety / Noise Immunity

Specification
Circuit Current Voltage Withstand Voltage
Power 3 10A 380VAC 600VDC
Signal 6 2A 24VDC 600VDC
Dielectric Strength 500VAC@50Hz, 60s Contact Material Precious Metal
Insulation Strength 1000MΩ@500VDC Housing Material Aluminium Alloy
Rotating Speed 300rpm Protection Level IP54
