12 Rings Capsule Slip Ring 300rpm With Silver Plated Teflon Wires / High Signal Fidelity
12 Rings Capsule Slip Ring 300rpm With Silver Plated Teflon Wires / High Signal Fidelity
12 Rings Capsule Slip Ring 300rpm With Silver Plated Teflon Wires / High Signal Fidelity
12 Rings Capsule Slip Ring 300rpm With Silver Plated Teflon Wires / High Signal Fidelity
Specifications
Brand Name :
Panlink
Model Number :
PSR-C12J
Certification :
ISO 9001: 2015, CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Packaging Details :
Carton Box, EPE Foam, Wooden Box(For Large Goods)
Name :
Capsule Slip Ring
Rings :
12 Rings
Voltage :
240VAC/VDC
Speed :
300rpm
Contact Material :
Precious Metal
Housing Material :
Aluimminium Alloy
Lead Wires :
Silver-Plated Teflon Wires
Price :
Negotiable
Delivery Time :
4 Weeks
Supply Ability :
40 Million a Year
Description

12 Rings Compact Capsule Slip Ring Equipped with Silver-Plated Teflon Wires Combining High Signal Fidelity with Stable Electrical Performance

Feature Application
• 12 circuit models • CCTV pan / tilt camera mounts
• 2 amp / 240 VAC circuits • Electrical test equipment
• Speeds up to 300 rpm • Manufacturing and process control equipment
• Contact Material: Precious Metal • Exhibit / display equipment
• Housing Material: Aluminium Alloy • Medical equipment
• Silver-Plated Teflon Wires

12 Rings Capsule Slip Ring 300rpm With Silver Plated Teflon Wires / High Signal Fidelity

Model Size: D x L(mm) Circuits Current Volatge Operational Speed
PSR-C12J 44 x 26.4 12 2 amp 240VAC/VDC 300rpm
Specification
Insulation Resistance 500MΩ@500VDC max
Electric Noise 40mΩ max
Dielectric Strength 500VAC@50Hz
Torque 0.01N*M
Lifetime 5 million revolutions
Humidity 60%RH
Working Temperature -20℃~+50℃
Contact Material Precious Metal
Lead Wires Silver-Plated Teflon Wires
