Compact Precision Capsule Slip Ring With 10 Million Revolutions / Signal Transmission
Compact Precision Capsule Slip Ring With 10 Million Revolutions / Signal Transmission
Compact Precision Capsule Slip Ring With 10 Million Revolutions / Signal Transmission
Compact Precision Capsule Slip Ring With 10 Million Revolutions / Signal Transmission
Specifications
Brand Name :
Panlink
Model Number :
PSR-M6PC
Certification :
ISO 9001: 2015, CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Packaging Details :
Carton Box, EPE Foam, Wooden Box(For Large Goods)
Name :
Capsule Slip Ring
Rings :
6 (1A/Ring)
D x L(mm) :
12 x 28
Insulation Resistance :
1000MΩ @ 500V DC
Lifetime :
10 Million Revolutions
Contact Material :
Gold-Gold
Lead Wires :
Stator: Kyocera 6298 Connector with 6 Pins, 146MM FPC
Price :
Negotiable
Delivery Time :
4 Weeks
Supply Ability :
40 Million a Year
Description

Compact Precision Miniature Capsule Slip Ring with a Super Long Lifespan of 10 Million Revolutions and High Qulity Signal Transmission

Feature Application
• Rings: 6 (1A/Ring) • Industrial Robotics
• D x L(mm): 12 x 28 • Precision Rotary Tables
• High Insulation Resistance. As high as 1000MΩ @ 500V DC • Security & Surveillance

• Long life. 10 million total revolutions at speeds up to 300 rpm have

• Test & Measurement Equipment
been obtained • Medical Equipment

• Gold-on-gold sliding contact technology

 • Aerospace & Defense
• Lead Wires: Stator: Kyocera 6298 Connector with 6 Pins, 146MM
FPC

Compact Precision Capsule Slip Ring With 10 Million Revolutions / Signal Transmission

Specification
Model PSR-M6PC
Circuits 6
Current 1A/Ring
Voltage 240VAC
Insulation Resistance 200MΩ@500VDC
Dielectric Strength 1000VAC@50Hz
Electrical Noise 40mΩ, max
Rotating Speed 300rpm
Torque Max 0.2N.M
Lifetime 10 million revolutions
Working Temperature -40℃~+80℃
Storage Temperature -45℃~+85℃
Humidity 60%
Contact Material Gold-Gold
Housing Material Aluminium Alloy
Leadwire

Rotor: AWG28# Teflon Silver Plated Wire

Stator: Kyocera 6298 Connector with 6 Pins, 146MM FPC
