Precision Capsule Slip Ring 48VDC Electric Slip Rings For Low Signal / Low Power Transmission
Precision Capsule Slip Ring 48VDC Electric Slip Rings For Low Signal / Low Power Transmission
Precision Capsule Slip Ring 48VDC Electric Slip Rings For Low Signal / Low Power Transmission
Precision Capsule Slip Ring 48VDC Electric Slip Rings For Low Signal / Low Power Transmission
Specifications
Brand Name :
Panlink
Model Number :
PSR-C25-02
Certification :
ISO 9001: 2015, CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Packaging Details :
Carton Box, EPE Foam, Wooden Box(For Large Goods)
Name :
Capsule Slip Ring
Rings :
25 Rings
Voltage :
48VDC
Electrical Noise :
≤20mΩ
Contact Material :
Precious Metal
Price :
Negotiable
Delivery Time :
4 Weeks
Supply Ability :
40 Million a Year
Description

Precision Slip Ring for Low-Signal/Low-Power Transmission with Exceptional Signal Fidelity

Features Applications

• 25 circuits deliver abundant signal and power paths

• Unmanned Aerial Vehicles & Unmanned Ground

• Ultra-long mechanical life

Vehicles

• High insulation resistance ensures signal integrity

• Robotic Joints

• Ultra-low contact resistance preserves the fidelity

• Automation Equipment & Winding Systems

of delicate analog and low-power digital signals

• Medical Devices
• Precision Rotating Test Equipment & Turntables

Precision Capsule Slip Ring 48VDC Electric Slip Rings For Low Signal / Low Power Transmission

Model Circuits Voltage

Length

inch(mm)

OD

inch(mm)

Speed

(rpm)
PSR-C25-02 25 x 2A 48VDC 1.94″(49.2) 0.87″(22) 300
Specifications
Insulation Resistance 20MΩ@200VDC
Electric Noise 20mΩ max
Dielectric Strength 200VAC@50Hz
Torque 50 gf.cm
Lifetime 10 million revolutions
Humidity 60%RH
Working Temperature -40℉~+176℉(-40℃~+80℃)
Storage Temperature -40℉~+176℉(-40℃~+80℃)
Protection Level IP54
Contact Material Precious Metal
Housing Material Plastic
