Slip Ring with 20-Million-rotation Longevity, a Dedicated Gigabit Ethernet Channel, and Minimal Torque, Delivering a Persistent and Stable Rotating Connection for High-data-rate Applications
Slip Ring with 20-Million-rotation Longevity, a Dedicated Gigabit Ethernet Channel, and Minimal Torque, Delivering a Persistent and Stable Rotating Connection for High-data-rate Applications
Slip Ring with 20-Million-rotation Longevity, a Dedicated Gigabit Ethernet Channel, and Minimal Torque, Delivering a Persistent and Stable Rotating Connection for High-data-rate Applications
Slip Ring with 20-Million-rotation Longevity, a Dedicated Gigabit Ethernet Channel, and Minimal Torque, Delivering a Persistent and Stable Rotating Connection for High-data-rate Applications
Specifications
Brand Name :
Panlink
Model Number :
PSR-C16-6S1G-02
Certification :
ISO 9001: 2015, CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
40 Million a Year
Delivery Time :
4 Weeks
Packaging Details :
Carton Box, EPE Foam, Wooden Box(For Large Goods)
Ethernet Connection(s) :
1 Channels 1000M BaseT
Torque :
0.025 N·cm
Lifetime :
20 million revolutions
OD x L :
0.87″ x 1.1″ (22 mm x 28mm)
Description

Slip Ring with 20-Million-rotation Longevity, a Dedicated Gigabit Ethernet Channel, and Minimal Torque, Delivering a Persistent and Stable Rotating Connection for High-data-rate Applications

10M+ Rotation Precision Ethernet Slip Ring

Features Applications

• Compliant with 1 Group 1000BaseT Ethernet

 • High-End Industrial Robots and Automation Equipment

• Low torque available for high-precision,

vibration-sensitive equipment

• Rotating Structures in Confined Spaces and High-

Temperature Environments

• Wide temperature range

 • Precision Test and Measurement Turntables

• Total Rings:15

 • Medical Imaging Equipment

• Voltage: 220VDC

 • Specialized Industrial Machinery

Slip Ring with 20-Million-rotation Longevity, a Dedicated Gigabit Ethernet Channel, and Minimal Torque, Delivering a Persistent and Stable Rotating Connection for High-data-rate Applications

Model Gbit Ethernet Signal Channels

OD x L

inch(mm)

 Circuits Voltage Total Rings
PSR-C16-6S1G-02 1 ×

0.87″ x 1.1″

(22 x 28)

 2A 220VDC 15
Specifications
Network Signal Signal
Insulation Resistance 500MΩ@100VDC 500MΩ@300VDC
Dielectric Strength 100VAC@50Hz 300VAC@50Hz
Electrical Noise Max. 10mΩ
Torque Max. 26gf.cm
Speed 250rpm
Lifetime 20 million revolutions
Working Temperature -49℉ to +212℉(-45℃ to +100℃)
Relative Humidity 85%
Protection Level IP51
Contact Material Precious Metal
Housing Material Aluminum Alloy
Lead Wire AWG26# Teflon Wire
