Medical Equipment 100BaseT Ethernet Slip Ring With 19 Pin HDMI / Ethernet Integration
Medical Equipment 100BaseT Ethernet Slip Ring With 19 Pin HDMI / Ethernet Integration
Medical Equipment 100BaseT Ethernet Slip Ring With 19 Pin HDMI / Ethernet Integration
Medical Equipment 100BaseT Ethernet Slip Ring With 19 Pin HDMI / Ethernet Integration
Specifications
Brand Name :
Panlink
Model Number :
PSR-C36-6P2S1E-HDMI
Certification :
ISO 9001: 2015, CE
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Packaging Details :
Carton Box, EPE Foam, Wooden Box(For Large Goods)
Name :
Ethernet Slip Ring
Video Connections :
19-pin HDMI 1080P@60Hz
Ethernet Connections :
100BaseT Ethernet
D x L :
0.87″ x 2.27″(22mm x 57.6mm)
Housing Material :
Aluminum Alloy
Price :
Negotiable
Delivery Time :
4 Weeks
Supply Ability :
40 Million a Year
Description

Stable Slip Ring with 19-pin HDMI and Ethernet Integration, Designed for Equipment that Requires Rotating Transmission of High-Definition Video

1 Group HDMI+ 1 Group 100M Ethernet

Features Applications

• Video Connections:19-pin HDMI 1080P@60Hz

• Security Surveillance

• Ethernet Connections: 100BaseT Ethernet

• Display and Broadcasting Equipment

• D x L: 0.87″ x 2.27″(22mm x 57.6mm)

• Medical Equipment

• Housing Material: Aluminum Alloy

• Radar and Sensing Equipment

Medical Equipment 100BaseT Ethernet Slip Ring With 19 Pin HDMI / Ethernet Integration The cable is supplied terminated with a HDMI connector.


Medical Equipment 100BaseT Ethernet Slip Ring With 19 Pin HDMI / Ethernet Integration

Model

100BaseT

Ethernet

 HDMI

OD x L

inch(mm)

 Circuits Voltage
PSR-C36-2P21E-HDMI 1 1 0.87″ x 2.27″(22 x 57.6) 33 240VDC
Specifications
Insulation Resistance 50MΩ@100VDC
Electrical Noise Max. 10mΩ
Dielectric Strength 100VAC@50Hz
Speed 100rpm
Lifetime 10 million revolutions
Working Temperature -40℉ to +176℉(-40℃ to +80℃)
Protection Level IP51
Contact Material Precious Metal
Housing Material Aluminum Alloy
Lead Wire Teflon Wire
