8041-HD Medical Suture Diameter Tester
8041-HD Medical Suture Diameter Tester
8041-HD Medical Suture Diameter Tester
8041-HD Medical Suture Diameter Tester
8041-HD Medical Suture Diameter Tester
8041-HD Medical Suture Diameter Tester
Specifications
Brand Name :
HAIDA
Model Number :
8041-HD
Place of Origin :
Guangdong, China
MOQ :
1
Type :
Storage water tank
Accuracy Class :
Standard Accuracy
Accuracy :
Within ±15%
Application :
PV
customized support :
OEM, ODM
power :
220V 50Hz
Protection Class :
/
Voltage :
220V Electrical Equipment
warranty :
1 Year
Internal Dimension :
700*700*1200mm
External Dimension :
1000*1000*1320mm
Max sample size :
300*400*100mm
Sample Lifting Method :
Equip electric hoist for carry sample up and down
Sample weight :
Maximum up to 100kg
Power :
Single phase, 220V 50Hz
Test Standard :
IEC 60529 - IPX7
Description
8041-HD Medical Suture Diameter Tester
Product Features

Equipped with a 7-inch K600+ core/dot matrix 65-color touchscreen display at 800*480 resolution. The PLC control system dynamically displays the loading force value. The operable interface is selectable: Chinese/English/Chinese-English switchable. It features digital closed-loop control, an AD acquisition speed of 500KHz, and an internal resolution of 500,000 counts. Includes a high-precision clock chip for power-off storage and overload alarm with automatic shutdown protection. Touch controls include: Nominal Size, Test Load, Print, Test, Move Left, Move Right, Time, and Calibration. Utilizes weight loading for tension, automatically records diameter data, automatically outputs data reports, and prints test results via the built-in printer.

Design Standards

Manufactured in accordance with the clauses related to diameter testing in standards YY1116-2020 "Absorbable Surgical Suture" and YY0167-2020 "Non-Absorbable Surgical Suture".

Technical Parameters
Parameter Specification
Nominal Size Range 12-0 to 10 medical sutures
Diameter Measurement Range 0–5 mm
Measurement Error ≤ ±1‰
Resolution 0.001 mm
Presser Foot Diameter 12.7 ± 0.02 mm
Reference Plate Diameter 50 mm
Presser Foot & Plate Flatness ≤ ±0.005 mm
Presser Foot & Plate Parallelism ≤ 0.5%
Loading Weights Range 0–2 Kg
Weight Accuracy ±0.1 g
Presser Foot Load ≤60 g, 210 g ± 3 g
Print Method Can print 3-point (1/4, 1/2, 3/4 positions) measurement data and average value; Can print the average of 10 tests, their overall average, and deviation.
Shipping List Main unit x1, Certificate of Conformity x1, Matching fixtures, Operation manual x1, Printer paper x1 roll, Matching hook weights.
Power Supply AC 90V-240V / 50Hz
Data Saving Onboard dot matrix printer / USB export to computer
Net Weight 38 kg
Overall Dimensions 320 * 1200 * 280 (mm)
