IEC62619-CB Wall Mounted Battery Storage 51.2V 280Ah 14.34kWh Batteries For Home Energy Storage
IEC62619-CB Wall Mounted Battery Storage 51.2V 280Ah 14.34kWh Batteries For Home Energy Storage
Specifications
Certification :
IEC62619-CB,CE.UN38.3
Place of Origin :
CHINA
MOQ :
1
Price :
$1600-1800
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Battory Rated Energy (kWh) :
14.34kwh
Description
Easy-Install 14.34kWh 51.2V Wall-Hung Solar Battery with 6000 Cycles
This low-voltage energy storage battery provides efficient and reliable energy storage solutions for households, businesses, and specialized applications. Featuring top-tier lithium iron phosphate battery cells with high safety, stability, energy density, and long cycle life. The built-in intelligent battery management system (BMS) comprehensively monitors and controls the energy storage system to ensure safe, stable, and high-performance operation.
Product Highlights
Safe Operation
  • A-grade lithium iron phosphate battery with high safety performance
  • Intelligent BMS with multiple safety functions for enhanced protection
  • Optional pre-installed fire extinguisher system available
Long Lifespan
  • Cycle life exceeding 6000 cycles (70% state of health)
  • High parallel balancing current ensures battery consistency
Convenient & Smart Features
  • Bluetooth/WiFi connectivity for real-time monitoring via mobile app
  • Remote software upgrade capability
  • Bluetooth/WiFi inverter protocol configuration for quick setup
  • Automatic networking of battery modules for easy maintenance
Flexible Installation
  • Compact size with high power density for space-limited installations
  • Unique dual-positive and dual-negative terminal design enables direct stacking and parallel connection without additional busbars
  • Compatible with mainstream low-voltage energy storage inverters
Manufacturing Advantages
  • Factory direct supply with efficient order processing
  • Flexible production capacity supporting small batch trial orders (MOQ 1 unit)
  • Customization services available for product parameters including voltage and interface specifications
IEC62619-CB Wall Mounted Battery Storage 51.2V 280Ah 14.34kWh Batteries For Home Energy Storage
Technical Specifications
Model CH--LVWES15-G1
Battery Type LiFePO4
Rated Energy 14.34 kWh
Rated Capacity 280 Ah
Scalability Parallel connection up to 16 units
Nominal Voltage 51.2 V
Operating Voltage 43.2~57.6 V
Recommended Charge/Discharge Current 140 A
Maximum Charge/Discharge Current 200 A
Recommended Depth of Discharge ≤90%
Dimensions (W/H/D) 520*680*232 mm
Weight 114 kg
IP Rating IP20
Operating Temperature Charge: 0~+55°C / Discharge: -20~+55°C
Storage Temperature -20~+35°C
Cycle Life ≥8000 cycles (25±2°C, 0.5C/0.5C, 70% EOL)
Installation Wall-Mounted/Floor-Mounted (optional wheel)
Fire Prevention System Optional prefabricated whole fluorine ketone fire extinguishing device
Communication CAN2.0/RS485
Warranty Period 10 years
Certification IEC62619-CB, CE, UN38.3
Compatible Inverters SMA, Victron, SE, Deye, Solis, Goodwe, Growatt, Luxpowertek, Senergy, SRD, etc.
