Residential Energy Storage 5.12kWh 25.6V 200Ah Battery Power Storage For Homes
Residential Energy Storage 5.12kWh 25.6V 200Ah Battery Power Storage For Homes
Specifications
Certification :
CE
Place of Origin :
china
MOQ :
1
Price :
$700-$1000
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Voltage :
48 V
Capacity :
5 kWh
Safety Certifications :
UL 9540, IEC 62619
Warranty :
10 years
Communication Interface :
CAN, RS485, WiFi
Mounting :
Wall-mounted
Description
5KWH Power Wall Type Lithium Iron Phosphate Battery
Product Overview
This modular-designed power wall battery features high integration for space-saving installation. Utilizing high-performance lithium iron phosphate cathode material, the battery cells demonstrate excellent consistency with a design lifespan exceeding 10 years. Front-facing operation, wiring, and one-key power switching enable easy installation, maintenance, and operation.
Advanced Protection & Compatibility
Comprehensive safety functions include over-temperature alarm protection, over-charge and over-discharge protection, and short-circuit protection. The system offers strong compatibility with seamless integration to UPS systems, photovoltaic power generation, and other primary equipment. Multiple communication interfaces including CAN/RS485 can be customized according to customer requirements for remote monitoring and flexible system utilization.
Key Product Features
  • Wall-mounted installation saves valuable space
  • Multiple parallel connection capability for easy system expansion with automatic addressing (no manual coding required)
  • Standard LCD display for real-time battery status monitoring and direct inverter communication selection
  • Environmentally friendly materials free from heavy metals and pollutants
  • Standard cycle life exceeding 5000 cycles
other
Factory Direct Supply: Own production base with direct order processing to ensure supply efficiency

Flexible Production Capacity: Support for small batch trial orders (MOQ 1 unit)

Customization Service: Product parameters (such as voltage, interface) can be customized according to customer requirements
Residential Energy Storage 5.12kWh 25.6V 200Ah Battery Power Storage For Homes
  • Residential Energy Storage 5.12kWh 25.6V 200Ah Battery Power Storage For HomesResidential Energy Storage 5.12kWh 25.6V 200Ah Battery Power Storage For Homes
Model CH-GBP24-200W
Nominal Voltage (V) 25.6
Cell Specification 100
Nominal Capacity (Ah) 200
Nominal Energy (kWh) 5.12
Operating Voltage Range (V) 22.4~29.2
Recommended Charging Voltage (V) 27.6
Recommended Discharge Cut-off Voltage (V) 24
Standard Charge/Discharge Current (A) 0.5C
Maximum Continuous Charge/Discharge Current (A) 1C (Customizable)
Operating Temperature (°C) -30~60 (Recommended 10~35)
Allowable Humidity Range (%RH) <85
Storage Temperature (°C) -20~65 (Recommended 10~35)
Charging Temperature (°C) 0~55
Discharging Temperature (°C) -10~55
Protection Level IP20
Cooling Method Natural Air Cooling/Intelligent Fan
Cycle Life 5000+ Times at 80% DOD
Maximum Dimension (D*W*H) mm 687*450*186
Weight (kg) 49
