UN38.3 Home Power Battery Storage 51.2V 100Ah 5.12kWh Household Energy Storage
UN38.3 Home Power Battery Storage 51.2V 100Ah 5.12kWh Household Energy Storage
Specifications
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
$700-900
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Recommend Depth of Discharge(%) :
≤90
Charge/Discharge Current (A)-Max. :
100
Description
Easy-Install 5kWh Wall-Hung Household Solar LFP Battery
This low-voltage energy storage battery provides efficient and reliable energy storage solutions for households, businesses, and specialized applications. Featuring top-tier lithium iron phosphate battery cells with high safety, stability, energy density, and long cycle life. Built-in intelligent battery management system (BMS) comprehensively monitors and controls the energy storage system to ensure safe, stable, and high-performance operation.
Product Highlights
Safe Operation
  • A-grade lithium iron phosphate battery with high safety performance
  • Intelligent BMS with multiple safety functions for enhanced protection
  • Optional pre-setting fire extinguisher system available
Long Lifespan
  • Cycle life exceeding 6000 cycles (70% State of Health)
  • High parallel balancing current ensures battery consistency
Convenient & Smart Features
  • Bluetooth/WiFi connectivity for real-time monitoring via mobile app
  • Remote software upgrade capability
  • Automatic battery module networking for easy maintenance
Flexible Installation
  • Compact size with high power density for space-limited installations
  • Dual-positive and dual-negative terminal design enables direct stacking and parallel connection without additional busbars
  • Compatible with mainstream low-voltage energy storage inverters
Technical Specifications
Model CH-LVWES05-G1
Battery Type LiFePO4
Rated Energy 5.12 kWh
Rated Capacity 100 Ah
Scalability Parallel connection up to 16 units
Nominal Voltage 51.2 V
Operating Voltage 43.2-58.4 V
Recommended Charge/Discharge Current 50 A
Maximum Charge/Discharge Current 100 A
Recommended Depth of Discharge ≤ 90%
Dimensions (W/H/D) 480 × 500 × 155 mm
Weight 47 kg
IP Rating IP20
Operating Temperature Charge: 0-60°C / Discharge: -20-60°C
Storage Temperature -20-35°C
Cycle Life ≥ 6000 cycles
Installation Wall-Mounted / Floor-Mounted
Communication CAN2.0 / RS485
Warranty Period 10 years
Certifications IEC62619-CB, CE, UN38.3
UN38.3 Home Power Battery Storage 51.2V 100Ah 5.12kWh Household Energy Storage
Manufacturing & Customization
Factory Direct Supply
Own production base ensures efficient order processing and quality control.
Flexible Production Capacity
Supports small batch trial orders with minimum order quantity of 1 unit.
Customization Service
Product parameters including voltage and interface specifications can be customized according to customer requirements.
Compatible Inverters
SMA, VICTRON, SE, DEYE, SOLIS, GOODWE, GROWATT, LUXPOWERTEK, SENERGY, SRD, and other mainstream brands
