Customized Ultrafiltration Water Treatment System Uf Filtration System 0.25T/H-1000T/H
Customized Ultrafiltration Water Treatment System Uf Filtration System 0.25T/H-1000T/H
Customized Ultrafiltration Water Treatment System Uf Filtration System 0.25T/H-1000T/H
Customized Ultrafiltration Water Treatment System Uf Filtration System 0.25T/H-1000T/H
Specifications
Brand Name :
Hongjie
Certification :
ISO 14001,ISO 9001,CE,EPA
Place of Origin :
Shenzhen,China
MOQ :
1set
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
>300sets/month
Delivery Time :
1-7working days(depand on raw materials stocking)
Packaging Details :
export standard wooden case
Production Capacity :
0.25T/H--1000T/H
Microbial & Bacterial Removal Rate :
99.99%
Suspended Solids Removal Rate :
99%
Backwash Pressure :
< 0.1 MPa
Backwash Flow Rate :
200 L/m²/hr
Chemical Cleaning :
Based on membrane material and fouling condition
RO system recovery rate :
96%
RO working voltage :
380V/220V/50Hz
Backwash Frequency :
Varies with feed water quality, 15 - 60 min
Backwash Duration :
30-60sec
Description

I.Flow Chart Of UF Water Treatment Equipment
Raw water pump - Sand filter - Carbon filter -Cartridge filter - High pressure pump- UF membrane host

II.Details of Product Description

Specification Description
Production Capacity 0.25T/H--1000T/H
Microbial & Bacterial Removal Rate 99.99%
Suspended Solids Removal Rate 99%
Backwash Pressure < 0.1 MPa
Backwash Flow Rate 200 L/m²/hr
Chemical Cleaning Based on membrane material and fouling condition
RO system recovery rate 96%
RO working voltage 380V/220V/50Hz

III.Equipment Overview
The ultrafiltration system is a membrane separation process that uses sieving as the separation principle and pressure as the driving force. The filtration precision ranges from 0.005 to 0.01 μm, effectively removing particles, colloids, bacteria, heat sources, and high-molecular organic substances from water. It can be widely used for the separation, concentration, and purification of substances. The ultrafiltration process involves no phase transformation and operates at normal temperature, making it especially suitable for the separation of heat-sensitive materials. It also boasts excellent resistance to temperature, acid, alkali, and oxidation, allowing for continuous operation under conditions of up to 60°C and a pH range of 2-11.

IV.Here is a guideline for you to get a proper quotation
Tell us the raw water/source of water(tap water, well water, or sea water, etc)
Provide water analysis report(TDS , conductivity, or resistivity, etc)
Required production capacity( 5m³/H, 50m³/H,or 500m³/H, etc)
What's the pure water used for( industrial,Food and Beverage,or agriculture, etc )
