Specifications
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Color :
Color
Supply Voltage :
3.3V
Brand Name :
Formike
Product Name :
Touch LCD IPS TFT 800x480 Resolution 5 Inch TFT LCD Display
Operating Temperature :
-20°C to 70°C
Supply Ability :
5000000000 pieces/year
Display Size :
5 inch
Packaging Details :
Tray + Inner Box + Carton
Touch Screen :
With resistive touch panel
Resolution :
800 x 480
Place of Origin :
China
Display Type :
5 Inch IPS TFT LCD Display
Model Number :
KWH050ST42-F02
Controller Ic :
ST7265
Payment Terms :
T/T,L/C,Credit card,Cash
Viewing Angle :
All
Dimensions :
120.7mm x 75.8mm x 4.0mm
MOQ :
1 piece
Interface :
40 Pin, 24 BIT RGB
Description

Touch LCD IPS TFT 800x480 Resolution 5 Inch TFT LCD Display

REACH ST7265 IPS 5 Inch TFT Display LCD Touch Screen 800x480

LCD Name Touch LCD IPS TFT 800x480 Resolution 5 Inch TFT LCD Display

Type

5 Inch LCD Display

Resolution

800X480

Response Time(ms)

30

Contrast Ratio

1200:1

Outline Dimension

120.70x 75.80 x 4.00mm

Active Area(HxV mm)

108.00x64.80mm

Viewing Direction

ALL

Interface

24 bit RGB, 40 Pin

Backlight

12 LED

Brightness

400cd/m2

Operating Temperature

-20℃~70℃

Backlight Supply Current/Voltage

40mA, 19.2V

With Resistive Touch Screen

* KWH050ST42-F02 is a Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight, RTP.

* It is 800x480 resolution TFT LCD module.

* Backlight with different brightness options from 200 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.

REACH ST7265 IPS 5 Inch TFT Display LCD Touch Screen 800x480REACH ST7265 IPS 5 Inch TFT Display LCD Touch Screen 800x480
