480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display
480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display
480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display
480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display
480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display
480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display
480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display
480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display
480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display
480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display
480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display
480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display
480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display
480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display
Specifications
Operating Temperature :
-20°C to 70°C
Resolution :
480 x 854
Product Name :
480x854 Resolution FWVGA LCD 5 Inch IPS Display TFT LCD Screen
Model Number :
KWH050ST20-F01
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Viewing Angle :
All
Place of Origin :
China
Supply Ability :
5000000000 pieces/year
Controller Ic :
NT35510
Payment Terms :
T/T,L/C,Credit card,Cash
Dimensions :
63.35mm x 118.50mm x 1.79mm
Supply Voltage :
3.7V
Display Type :
5 Inch IPS TFT LCD Screen
MOQ :
1 piece
Brand Name :
Formike
Packaging Details :
Tray + Inner Box + Carton
Display Size :
5"
Touch Screen :
Without (Optional with touch panel)
Color :
Color
Interface :
45 Pin, 16 BIT RGB
Description

480x854 Resolution FWVGA LCD 5 Inch IPS Display TFT LCD Screen

480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display

Product Name480x854 Resolution FWVGA LCD 5 Inch IPS Display TFT LCD Screen
LCD Size5 Inch TFT LCD Display Module
Display ModeIPS
Resolution480x854
Outline Dimension (mm)63.35x118.50x1.79
Active Area (mm)62.064x110.4222
Dot pitch (mm)0.1293x0.1293
Viewing DirectionAll
Interface16 BIT RGB Interface, 45 Pin
Driver ICNT35510
Brightness (Cd/m2)250
Contrast Ratio800:1
Backlight6 Serial 2 Parallel White LEDs = 12 White LEDs

Backlight Supply
(Current/Voltage)

40mA 19.2V
Touch ScreenWithout (Optional with)

* KWH050ST20-F01 is a Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight.

* It is 480x854 resolution TFT LCD module.

* Backlight with different brightness options from 250 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.

480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display480x854 NT35510 FWVGA LCD TFT Screen 5 Inch IPS Display
